81EU01E-E卡件,ABB中文PDF用戶手冊81EU01E-E
AC 800M和通信接口
緊湊型產品套件所有模塊概述有關AC 800M硬件的更新信息，請?jiān)L問我們的硬件選擇器。在選擇器中，可以比較
不同的通信模塊，S800 IO模塊，模塊終端裝置、AC 800M控制器、電源、投票者、，
面板，還可以打印您自己的pdf文件。通用域名格式
AC 800M是一系列軌道安裝模塊，由CPU、通信模塊、電源模塊及各種附件。有幾個CPU模塊可供選擇，從中等處理器功耗、低成本到高處理器
81EU01E-E卡件全冗余功能/CPU PM862 PM864A（經典）PM866A PM891的電源和支持
通過CNCP協議，AC 800M控制器之間的時鐘同步1 msCEX總線上的通信模塊12 12 12 12 12
CEX總線上的電源電流電源電流：最大24 V-2.4 A（保險絲3.15 A快速，PM891帶有嵌入式自動保險絲）Modulebus上的I/O群集
非冗余CPU1標高+7選項。1標高+7選項。1標高+7選項。0標高+7選項。Modulebus上的I/O群集
冗余CPU7光學0標高+7選項。0標高+7選項。0標高+7選項。
模塊總線上的輸入/輸出容量非冗余/冗余CPU
81EU01E-E卡件最多96/84個輸入/輸出模塊最多96/84個輸入/輸出模塊最多96/84個輸入/輸出模塊最多84/84個輸入/輸出模塊
Modulebus掃描速率0-100 ms（實際時間取決于輸入/輸出模塊的數量），PM865和PM867為0-300電氣上的電源電流
模塊總線電源電流：最大24 V-1.0 A（防短路，保險絲2.0 A），最大5 V-1.5 A（短路電路驗證）
AC 800M and Communication interfaces
Compact Product Suite
Outline of all modules
For updated information regarding AC 800M hardware please
visit our Hardware Selector. In the selector you can compare
different communication modules, S800 IO modules, module
termination units, AC 800M controllers, power supplies, voters,
panels and also print your own pdf files.
www.compacthardwareselector.com
AC 800M is a family of rail-mounted modules, consisting of CPUs, communication
modules, power supply modules and various accessories. There are several CPU modules
to choose from, ranging from medium processor power and low cost to high processor
power and support for full redundancyFeatures / CPUs PM862 PM864A (Classic) PM866A PM891
Clock synchronization 1 ms between AC 800M controllers by CNCP protocol
Comm. modules on CEX bus 12 12 12 12
Supply current on CEX bus Supply current: Max 24 V - 2.4 A (fuse 3.15 A fast, PM891 has an embedded auto fuse)
I/O clusters on Modulebus with
non-redundant CPU
1 el. + 7 opt. 1 el. + 7 opt. 1 el. + 7 opt. 0 el. + 7 opt.
I/O clusters on Modulebus with
redundant CPU
7 optical 0 el. + 7 opt. 0 el. + 7 opt. 0 el. + 7 opt.
