PFSK151數據通信模塊,PFSK151中文PDF使用手冊
通信模塊允許羅克韋爾自動化
ControlLogix處理器可輕松與其他處理器連接
Modbus協議兼容設備。PFSK151
兼容設備不僅包括Modicon PLC
(均支持Modbus協議)但終端設備分類。該模塊充當
Modbus網絡和羅克韋爾自動化背板。

數據傳輸
來自處理器的操作與上的操作是異步的
Modbus網絡。中的5000字寄存器空間
模塊在處理器和之間交換數據
PFSK151數據通信模塊
Modbus網絡。
功能和優點
inRAx Modbus主/從通信
模塊的設計允許ControlLogix處理器
易于與Modbus協議兼容的接口
設備和主機。
支持的功能代碼:HART通用
支持的命令集為00-03、06-09和11-22。
支持的HART常用命令集包括
33-83和105-110。
HART網絡通信:支持四種
主通道。模塊上的每個通道
獨立配置以模擬HART主機。
突發模式可用于從
從設備。
命令輪詢也是用戶可配置的,包括
禁用、連續、數據更改時(僅寫),以及
動態啟用用戶或自動。
狀態:HART協議返回的錯誤代碼
在單個命令的基礎上可用。此外,a
從屬狀態列表按活動信道進行維護。
其他產品
ProSoft技術提供了
針對各種
工業通信平臺。
The MVI56 Modbus Master/Slave
Communication Module allows Rockwell Automation
ControlLogix processors to interface easily with other
Modbus protocol compatible devices.
Compatible devices include not only Modicon PLCs
(which all support the Modbus protocol) but also a wide
assortment of end devices. The module acts as an
input/output module between the Modbus network and
the Rockwell Automation backplane. The data transfer
from the processor is asynchronous from the actions on
the Modbus network. A 5000-word register space in the
module exchanges data between the processor and the
Modbus network.
Features and Benefits
The inRAx Modbus Master/Slave Communications
module is designed to allow ControlLogix processors to
interface easily with Modbus protocol-compatible
devices and hosts.
