IDPG 940128102模塊,IDPG使用數據檢查歷史數據檢索畫面顯示正常，輸入正確的需檢索的數據（如測點名、測點編號）和檢索時間段，系統應正確響應，并顯示相應的歷史數據報表或歷史數據曲線、歷史事件報表、操作記錄、報警記錄等。若請求打印，則打印結果應與顯示結果相同。c 檢查報表管理功能畫面顯示正確，選中一張報表進行隨機（召喚）打印，系統響應正確，檢查報表內容正確。d 選擇一副流程圖畫面IDPG，觸發屏幕拷貝功能，系統響應正確，檢查硬拷貝和畫面應一致。通過系統自診斷信息檢查系統運行狀態，顯示正常。
檢查幫助和/或操作指導畫面顯示正常。根據畫面清冊檢查各流程畫面和參數監視畫面等應無缺少。（5）報表打印、事故追憶功能試驗。a 通過功能鍵盤或軌跡球/鼠標，在操作員站上選中系統內所有報表，并觸發隨機（召喚）打印功能，系統應立即打印選中的報表,檢查幫助和/或操作指導畫面顯示正常。根據畫面清冊檢查畫面和參數監視畫面等應無缺少。b 系統通電啟動后，模擬事件追憶觸發開關量點動作，檢查事件追憶報表打印應正常，數據和觸發開關量點動作前后時間應正確。在SOE能正確響應的基礎上，連續模擬數個開關量的動作，SOE應能按正確次序顯示并打印。c 驗證SOE的分辨率：加數各時間差略大于1ms的信號到SOE，應能正確分辨出每個信號以及信號的次序，報警顯示并打印。（6）歷史數據存儲和檢索功能試驗。從歷史數據庫中選取一組記錄點，內容應包括模擬量、開關量、操作記錄、系統事件等。分別組態當前時段（短期）的歷史數據報表和曲線，并顯示打印，報表、曲線的數據和時間應正確，整個操作過程應無故障報警。分別組態已轉儲至磁帶或光盤，插入相應的磁帶或光盤，予以激活，并顯示打印，報表、曲線的數據和時間應正確，整個操作過程應無故障報警。（7）性能計算功能檢查。啟動性能計算應用程序，應無出錯報警。檢查性能計算報表和畫面顯示應正常，打印性能計算報表，內容應正常，性能計算項目應無缺項。檢查與性能計算相關的所有測點應正常，指示正確。協同有關部門和單位檢查鍋爐各種熱損失、熱效率的計算、汽機熱耗IDPG 940128102
processing in time and effectively, as shown in Figure 2-3
2-3 schematic diagram of alarm information 3 system design the system is mainly composed of Le series PLC of Beijing Hollysys company as the core, ht7a00t touch screen, encoder, frequency converter, actuator, etc. It mainly detects the shape of stone through a number of microswitches, so as to control the lifting of grinding head, encoder controls swing arm, touch screen monitors and controls and sets relevant parameters. The touch screen configuration is ht7a00t of Hollysys company, Realize the monitoring and control of PLC control station, ensure the reliability and real-time of the system, and ensure the uninterrupted operation of the monitoring system. 4 application features the resin continuous mill system based on Le series PLC has the following characteristics: ? the stability and reliability system adopts Le series PLC and mature supporting scheme of
