PROSOFT MVI69E-MBS 通訊模塊
1.產 品 資 料 介 紹：
中文資料：
PROSOFT MVI69E-MBS通訊模塊是一款高性能的通信解決方案，專為工業自動化和控制應用而設計。它主要被用于將Modbus應用程序集成到Allen-Bradley ControlLogix系列可編程控制器（PLC）中，使得ControlLogix PLC能夠與其他Modbus兼容設備進行通信，如傳感器、執行器、儀表等。
這款模塊支持多種串行通信協議，如Modbus RTU、Modbus ASCII、DF1、ASCII等，從而能夠滿足工業自動化系統的多樣化需求。它具備數據轉換、協議轉換和通信優化等增強型功能，可以將不同協議之間的數據進行轉換，實現不同設備之間的透明通信，并優化通信性能，提高數據傳輸?shù)男屎头€(wěn)定性。
MVI69E-MBS模塊配有附加配置文件和附加指令，從而縮短調試時間。它有兩個串行端口，可支持主站和/或從站連接至各種使用Modbus協議的設備。此外，用戶自定義標簽UDT為I/O、模塊狀態和控制數據提供邏輯定義，進一步增強了其靈活性和便利性。
在硬件規格方面，該模塊功耗低，安裝在單個插槽中，并能夠在特定的溫度和濕度范圍內穩定運行。它還提供了豐富的LED指示燈，用于指示模塊狀態、背板活動、以太網端口活動和配置活動等。包裝中包括模塊本身、公頭適配器電纜、螺絲端子適配器和以太網電纜，為用戶提供了完整的解決方案。
總的來說，PROSOFT MVI69E-MBS通訊模塊是一款功能強大、性能穩定的通信解決方案，適用于各種工業自動化和控制應用。它能夠滿足用戶對于實時數據傳輸、快速響應和精確控制的需求，提高生產效率和質量。
英文資料
The PROSOFT MVI69E-MBS communication module is a high-performance communication solution designed specifically for industrial automation and control applications. It is mainly used to integrate Modbus applications into Allen Bradley ControlLogix series programmable controllers (PLCs), enabling ControlLogix PLCs to communicate with other Modbus compatible devices such as sensors, actuators, instruments, etc.
This module supports multiple serial communication protocols, such as Modbus RTU, Modbus ASCII, DF1, ASCII, etc., thus meeting the diverse needs of industrial automation systems. It has enhanced functions such as data conversion, protocol conversion, and communication optimization, which can convert data between different protocols, achieve transparent communication between different devices, optimize communication performance, and improve data transmission efficiency and stability.
The MVI69E-MBS module comes with additional configuration files and instructions to shorten debugging time. It has two serial ports that can support the connection of the master and/or slave stations to various devices using the Modbus protocol. In addition, user-defined tag UDT provides logical definitions for I/O, module status, and control data, further enhancing its flexibility and convenience.
In terms of hardware specifications, this module has low power consumption, is installed in a single slot, and can operate stably within specific temperature and humidity ranges. It also provides a variety of LED indicators to indicate module status, backplane activity, Ethernet port activity, and configuration activity. The packaging includes the module itself, male adapter cable, screw terminal adapter, and Ethernet cable, providing users with a complete solution.
Overall, the PROSOFT MVI69E-MBS communication module is a powerful and stable communication solution suitable for various industrial automation and control applications. It can meet the needs of users for real-time data transmission, fast response, and precise control, improving production efficiency and quality.
2.產 品 展 示
3.產 品 展 示
