Data Bus Structure
The data bus structure on the MVME147 is arranged to
accommodate the 8-bit, 16-bit, 32-bit, and 16/32-bit ports that
reside on the board. The 8-bit ports are connected to D24-D32 of the
local bus, 16-bit ports are connected to D16- D32 of the local bus and
32-bit ports are connected to D00-D32 of the local bus.
Battery Backed Up RAM and Clock
The SGS-Thompson M48T18 RAM and clock chip is used on the
MVME147. This chip provides a time-of-day clock, oscillator,
power fail detection, memory write protection, and 8184 bytes of
RAM. However, only 4088 bytes of RAM are accessible on the
MVME147. The battery and crystal plug into the M48T18.
have 2040 bytes of RAM available. Any programs
written to use RAM in the address range above the
TOD clock will not work on an earlier version
MVME147.
The internal battery has a typical life span of 3 to 5 years when the
clock is running and a minimum of 10 years when the clock has not
been put in operation.
Note The clock is shipped from the factory in the power-save
mode.
ROM/PROM/EPROM/EEPROM
There are four 32-pin ROM/PROM/EPROM/EEPROM sockets on
the MVME147. They are organized as 2 banks with two sockets per
bank.
The banks are configured as word ports to the MPU. Each bank can
be separately configured for 8K x 8, 16K x 8, 32K x 8, 64K x 8, 128K
x 8, 256K x 8, 512K x 8, or 1M x 8 ROM/PROM/EPROM devices or
2K x 8, 8K x 8, or 32K x 8 EEPROM devices.
There are several different algorithms for erasing/writing to
EEPROM devices depending on the manufacturer. The MVME147
supports only those devices which have a static RAM compatible
erase/write mechanism such as the Xicor X28256 or X2864H.
Device Timing Requirements
The ROM/PROM/EPROM/EEPROM devices must meet the
timings shown in Figure 5-2.
The ROM/PROM/EPROM/ EEPROM devices are guaranteed the
