以太網TCP/IP網絡的編程器和PLC您必須在以太網接口中設置IP地址。設置IP地址后，連接PLC和運行Windows軟件的程序員以太網接口。有關以太網TCP/IP的更多詳細信息，請參閱TCP/IP以太網通信（類型2）用戶手冊和Windows編程手冊，GFK-1295。配置IC697 CPU和輸入/輸出系統配置為基于MS-DOS或Windows的編程軟件。
BASLER A404k工業相機沒有DIP開關或跳線用于配置系統。CPU驗證實際通電時的模塊和機架配置，以及在運行期間定期。實際配置必須與編程的相同配置偏差報告給CPU配置故障的報警處理器功能回答參考參考文獻1了解配置功能。電池安裝鋰電池（IC697ACC701），如圖所示如圖2所示。該電池維護程序和數據當電源斷開并操作日歷時鐘。確保安裝新電拆卸舊電池之前。如果在通電期間診斷檢測到電池電量低，模塊OK LED（頂部LED）將不亮起。具體的電池電量低狀態的指示詳見參考2。卸下模塊當發生以下情況時，應遵循以下說明從機架中的插槽中卸下模塊。牢牢抓住電路板的頂部和底部將拇指放在面板正面的板蓋上將蓋子和手指放在塑料夾子上封面的背面。擠壓蓋背面的機架夾用手指將夾子從機架導軌并用力拉動板將其卸下從背板連接器。沿卡導軌滑動板并卸下它來自機架。
programmer and PLC to the Ethernet TCP/IP network
you must set the IP address in the Ethernet Interface.
After setting the IP address, connect the PLC and the
programmer running Windows software to the
Ethernet Interface.
For more detailed information on Ethernet TCP/IP,
refer to the TCP/IP Ethernet Communications (Type 2)
User’s Manual, and the Windows programming
manual, GFK-1295.Configuration
The IC697 CPU and I/O system is configured with
MS-DOS or Windows based programming software.
There are no DIP switches or jumpers used to
configure the system. The CPU verifies the actual
module and rack configuration at power-up and
periodically during operation. The actual
configuration must be the same as the programmed
configuration. Deviations are reported to the CPU
alarm processor function for configured fault
response. Consult Reference 1 for a description of
configuration functions.Battery
A lithium battery (IC697ACC701) is installed as shown
in Figure 2. This battery maintains program and data
memory when power is removed and operates the
calendar clock. Be sure to install the new battery
before removing the old battery. If during power-up
diagnostics a low battery is detected, the MODULE
OK LED (top LED) will not stay on. Specific
indication of a low battery state is detailed in
Reference 2.Removing a Module
The instructions below should be followed when
removing a module from its slot in a rack.
Grasp the board firmly at the top and bottom of
the board cover with your thumbs on the front of
the cover and your fingers on the plastic clips on
the back of the cover.
Squeeze the rack clips on the back of the cover
with your fingers to disengage the clip from the
rack rail and pull the board firmly to remove it
from the backplane connector.
Slide the board along the card guide and remove
it from the rack.
