圖形窗口重新繪制或更新速度緩慢這可能是由于計算機的性能不夠高，無法滿足工作站中幾何文件的大小。要減小幾何圖形文件的大小，請執行以下任一操作：?使用較低的細節級別渲染幾何圖形。有關更多信息，請參見第387頁的圖形外觀。?通過使用“延時”功能，可以自動簡化融合、倒角和孔。這可以大大降低圖形復雜性、加快模擬速度并減少內存使用。?檢查對象是否包含不必要的詳細信息。刪除編程或模擬不需要的細節。部分幾何體不可見如果部分幾何體在某些視圖中不可見，可能的原因是對象由2D曲面組成，并且啟用了“背面剔除”選項，如果對象（或其任何面）的方向不同，它們將不可見。
e graphics window
redraws or updates slowly
This might be due to the performance of your computer not
being high enough for the size of the geometry files in your
station.
To reduce the size of the geometry files, do any of the following:
? Use a lower detail level for rendering the geometry. For
more information, see Graphic Appearance on page
387.
? Blends, chamfers and holes can be automatically
simplified by using the Defeature function. This can
greatly reduce graphic complexity, speed up simulations
and reduce memory usage.
? Check if the object has unnecessary details. Remove
details that are not necessary for your programming or
simulation.Parts of the geometry are
not visible
If parts of the geometry are not visible from some views, a
probable cause is that the object is made up of 2D surfaces and
the option Backface culling is on.
Backface culling means that the faces of the object are only
visible from the front, and if the object (or any of its faces) is
oriented differently, they will not be visible.
