WOODWARD 9907-173輸出模塊
后配置安裝
或刪除硬件組件后，請執行以下步驟。1.確保按照說明安裝所有組件。2.確保電腦內沒有工具或松動部件。3.重新安裝以前卸下的所有擴展板、外圍設備和系統電纜。4.根據第26頁的說明重新安裝機箱蓋。5.重新連接計算機的所有外部電纜和電源。6.按下電源開關啟動計算機。部件更換工具部件更換需要以下工具：?2號十字頭螺絲刀?防靜電腕帶?側切刀（如有必要，用于切割電纜扎帶）重要事項安裝硬件或執行需要訪問內部部件的維護程序時，我們建議您先備份所有計算機數據以避免丟失。注意：在開始配置計算機硬件之前，請務必閱讀并理解所有安裝和刪除過程。
拆除蓋子要安裝
更換或升級內部計算機組件，必須首先拆除蓋子。按照以下步驟卸下后蓋（顯示的是顯示計算機）。1.按照第24頁的預配置步驟進行操作。2.擰松固定后蓋（A）的三個螺釘。3.打開蓋（B）并將其從機箱（C）上拆下。4.安裝、更換或升級內部計算機組件后，按照第26頁“重新安裝蓋子”中的詳細說明重新安裝蓋子。A B A C C 26《用于危險場所的工業計算機》自動化出版物6181X-IN001D-EN-P-2015年7月重新安裝蓋子按照以下步驟重新安裝后蓋（顯示計算機）。1.按照第24頁“后配置”的步驟1…3。2.將后蓋重新連接到機箱（A）。3.關閉蓋子（B）。4.擰緊固定后蓋（C）的三個螺釘。5.按照第24頁上的步驟4和5進行后期配置。C B C C A A危險場所工業計算機27自動化出版物計算機有兩個位置用于加載CompactFlash（CF）II型卡：?一個固態驅動器托架位于計算機側面。安裝在此托架中的卡是可引導的，并用作主驅動器。
Post Configuration Installation
Or after removing the hardware components, perform the following steps. 1. Make sure all components are installed according to the instructions. 2. Make sure there are no tools or loose parts in the computer. 3. Reinstall all expansion boards, peripherals, and system cables that you removed previously. 4. Reinstall the cover as described on page 26. 5. Reconnect all external cables and power supplies to the computer. 6. Press the power switch to start the computer. Parts replacement tools Parts replacement requires the following tools: ? No. 2 crosshead screwdriver ? Anti static wrist strap ? Side cutter (if necessary, it is used to cut cable ties) Important When installing hardware or performing maintenance procedures that require access to internal parts, we recommend that you first back up all computer data to avoid loss. Note: Before you start configuring your computer hardware, be sure to read and understand all the installation and removal procedures.
Remove the cover and install it
To replace or upgrade internal computer components, you must first remove the cover. Follow the steps below to remove the back cover (the display computer is shown). 1. Follow the pre configuration steps on page 24. 2. Loosen the three screws that fix the back cover (A). 3. Open the cover (B) and remove it from the chassis (C). 4. After installing, replacing, or upgrading the internal computer components, reinstall the cover as detailed in "Re installing the cover" on page 26. A B A C C 26 Industrial Computers Used in Hazardous Locations Automation publication 6181X-IN001D-EN-P-2015 Reinstall the cover in July 2015 Follow the steps below to reinstall the back cover (display computer). 1. Follow steps 1... 3 of "Post configuration" on page 24. 2. Reconnect the back cover to the chassis (A). 3. Close the cover (B). 4. Tighten the three screws fixing the rear cover (C). 5. Follow steps 4 and 5 on page 24 for later configuration. C B C A A Industrial computer in hazardous locations 27 Automation publication computer has two locations for loading CompactFlash (CF) II cards: ? One solid-state drive bay is located on the side of the computer. The card installed in this bay is bootable and serves as the primary drive.
