電機為交流異步電機，紙機設計最高轉速為1800m/min,傳動控制系統為T(mén)Mdrive-10e2，PWM控制的交直交變頻矢量控制系統，功率元件采用絕緣柵雙極晶體管(IGBT)。
傳動逆變器柜類型較多，250KVA以下為抽屜式，250KVA以上為柜式結構，根據電機容量的差異來選用不同容量控制系統，用于紙機的變頻控制。
逆變器的傳動矢量控制組成：速度給定環節、速度調節器、D/Q軸電流調節器、磁通調節器、電壓調節器、PWM控制器等組成。主板在矢量控制系統完成IGBT觸發信號后，把觸發脈沖傳送到逆變器，控制IGBT導通和關斷，得到所需電機近似于正弦波的輸入電壓和頻率，進而調節電機轉速。
2.4 數據通信
傳動系統和PLC間通信采用FL-NET總線,光纖連接，變頻器與HUB之間，以太網通訊。結構仍以圖2為例。
PLC系統配置了一塊FL612接口模塊和一塊EGD模塊，與各變頻器進行數據交換。各變頻器地址均在EGD中配置，傳動與PLC的通信及傳動與傳動之間的通信都是通過EGD來完成數據交換的。
FL-NET網絡以Ethernet為物理層，采用總線拓?fù)浣Y(jié)構，是日本采納的一種PLC網絡標準，其協議棧高層為UDP/IP+ UDP/IP+獨自循環通信協議，保證了通信的實時性。
完成PLC系統與傳動系統間數據交換基于EGD(Ethernet Global Data)以太網全局?jǐn)?shù)據處理通信，EGD協議是美國GE自動化公司基于以太網技術的數據交換協議，它以數據報文形式在一個發送者和多個發送者之間實現100Mbps數據高速傳送，遵循UDP/IP獨自循環通信協議。數據發送時間間隔短，安全性強，不易丟失，各站為雙向角色，既是服務器也是客戶端。
3. 系統控制功能
TMEIC集成控制器完成整個紙機的速度計算與控制、負荷分配計算與控制、電機同步計算與保護等功能。
衛生紙機的速度基準以烘缸Yankee為準，Yankee烘缸由兩臺電機驅動，1#Yankee電機為master，控制方式為速度控制，2#Yankee電機為slave，控制方式為轉矩控制，兩臺電機為一個整體，要求速度同步。generation of control system will fully meet or exceed that of similar imported brand equipment, and meet the upgrading of equipment, with considerable flexibility and expansion.
