DSDI 451 擴展單元 - 數字輸入
內部緊湊型閃存卡
可用于擴展項目?jī)?nèi)存。操作員面板支持I型和II型緊湊型閃存卡。推薦的緊湊型閃存卡為SiliconSystems SiliconDrive、SanDisk工業級和Cactus 203-、302-、303系列。安裝執行以下步驟在操作面板中安裝內部Compact Flash卡：1.關閉面板電源。2.使用梅花螺絲刀（T10*50）拆下操作面板上的后蓋使用內部Compact Flash存儲卡時，不能使用外部Compact閃存卡。外部USB閃存驅動器可用于與外部Compact閃存卡相同的功能。
如果CPU卡和電源卡彼此斷開連接的時間較長，重新組裝時面板可能無法啟動。要解決此問題，需要通過設置模式開關編號來執行硬件重置。翻轉后蓋；CPU板安裝在后蓋內部。4.將Compact Flash存儲卡插入CPU板上的插槽。5.將后蓋重新連接到操作面板。6.打開操作面板的電源。7.當操作面板啟動時，系統會詢問您是否要將文件移動到內部卡；對此問題選擇“是”。面板生成器800中的設置必須在操作員面板的配置工具中輸入內部存儲卡的大小。1.選擇設置/終端選項。2.在“存儲卡設置/內部”下輸入內部存儲卡的大小。
Internal compact flash memory card
Can be used to expand project memory. The operator panel supports Type I and Type II compact flash cards. The recommended compact flash memory cards are Silicon Systems Silicon Drive, SanDisk industrial grade and Cactus 203 -, 302 -, 303 series. Installation Perform the following steps to install the internal Compact Flash card in the operation panel: 1. Turn off the panel power. 2. Use a Torx screwdriver (T10 * 50) to remove the back cover on the operation panel. When using an internal Compact Flash memory card, you cannot use an external Compact Flash memory card. The external USB flash drive can be used for the same functions as the external Compact flash card.
Caution - If the CPU card and power card is disconnected from each other for a longer period of time, the panel may not boot when it is reassembled again. To remedy this problem, a hardware reset needs to be performed by setting the mode switch no.. Flip the back cover; the CPU board is mounted inside the back cover. 4. Insert the Compact Flash memory card in its slot on the CPU board. 5. Re-attach the back cover to the operator panel. 6. Turn on the power to the operator panel. 7. When the operator panel starts up, you will be asked if you like to move the files to the internal card; select YES to this question. Settings in Panel Builder 800 The size of the internal memory card must be entered in the configuration tool for the operator panel. 1. Select Setup/Terminal Options. 2. Enter the size of the internal memory card under Memory card settings/Internal. C
