DSCS116通訊端口模塊
SRAM通信端口以太網
規格（續）電源24 VAC 50/60 Hz@20 VA技術16位處理器2 MB（16兆位）閃存319 KB SRAM內存用于數據庫實時時鐘超級電容器用于72小時實時時鐘備份和SRAM通信端口以太網（10 BaseT）BACnet IP、BACnet over Ethernet 2 RS-485 NET1、NET2支持：BACnet MS/TP高達76800 bps，每個端口最多99個設備Delta LINKnet最高76800 bps，LINKnet上最多12個設備，不超過2個DFM設備（僅1個端口）可選Modbus最高68400 bps，最多5個設備（僅一個端口）串行RS-232 BACnet PTP，最高38400 bps環境溫度32°至131°F（0°至55°C）10至90%RH（非冷凝）尺寸105/16 x 4?x 115/16英寸。（26.2 x 10.7 x 4.9 cm），外殼重量0.959 lb（435 g），外殼符合CE FCC Listings C-UL Listed UL 916 Listed BTL Listed DSC-1180E：電路板布局圖版權所有?2016 Delta Controls。保留所有權利。如有更改，恕不另行通知。系統控制器訂購根據以下產品編號訂購帶有所需選項的DSC-1180E：附件DSC-1180 Delta系統控制器11輸入，8個模擬輸出DZNR-768 BACnet MS/TP TRM-768 Delta網絡中繼器BACnet MS/TP CON-768BT藍牙無線服務工具DFF099-CDT的Delta網絡終端Modbus flash key DFF099的額外50個信用塊預加載50個信用的Modbus flash upgrade key BACstat是Delta Controls股份有限公司的注冊商標。BACnet是美國采暖、制冷和空調工程師協會（ASHRAE）的注冊商標
SRAM communication port Ethernet
Specifications (continued) Power supply 24 VAC 50/60 Hz@20 VA technology 16 bit processor 2 MB (16 megabit) flash memory 319 KB SRAM memory for database real-time clock Supercapacitor for 72 hour real-time clock backup and SRAM communication port Ethernet (10 BaseT) BACnet IP, BACnet over Ethernet 2 RS-485 NET1, NET2 support: BACnet MS/TP up to 76800 bps, each port up to 99 devices Delta LINKnet up to 76800 bps, LINKnet up to 12 devices, No more than 2 DFM devices (only one port) Optional Modbus up to 68400 bps, up to 5 devices (only one port) Serial RS-232 BACnet PTP, up to 38400 bps Ambient temperature 32 ° to 131 ° F (0 ° to 55 ° C) 10 to 90% RH (non condensing) Size 105/16 x 4 ? X 115/16 in. (26.2 x 10.7 x 4.9 cm), enclosure weight 0.959 lb (435 g), enclosure complies with CE FCC Listings C-UL Listed UL 916 Listed BTL Listed DSC-1180E: Circuit Board Layout All Rights Reserved ? 2016 Delta Controls。 All rights reserved. Subject to change without notice. Ordering System Controllers Order DSC-1180E with the required options according to the following product numbers: AttachmentDSC-1180 Delta System Controller 11 Inputs, 8 analog outputs DZNR-768 BACnet MS/TP TRM-768 Delta network repeater BACnet MS/TP CON-768BT Bluetooth wireless service tool DFF099 Delta network terminal Modbus flash key DFF099 Additional 50 credit blocks preloaded with 50 credit Modbus flash upgrade key BACstat is a registered trademark of Delta Controls Co., Ltd. BACnet is a registered trademark of ASHRAE
