DSAX452
隔離電機注意此步驟
因為這是成功將任何機車轉換為DCC運行的最重要步驟。兩個電機電刷連接必須電氣隔離，以便它們僅由DSD電機輸出驅動。我們不是在開玩笑！數字聲音解碼器用戶手冊9停止未能正確隔離電機將損壞解碼器，并將其變成有效但壽命短的煙霧發生器！我們的保修明確排除因電機隔離不當而造成的損壞；但是，如果您損壞了解碼器，只需將其返回到Throttle Up！連同服務費（請注明當前金額），我們將及時維修并退還。從機車和招標框架上拆除鍋爐和招標外殼，開始電機隔離。在繼續之前，仔細檢查機車接線并確定每條線的位置和作用是很重要的。制造商的裝配圖在這里可能有用，或者您可以選擇創建自己的接線圖。特別是，您需要識別左側和右側電源拾取器的連接以及（+）和（-）電機連接。注：對于N、HO、S和O標尺機車，正電機連接是連接到右側軌道（工程師側）電源拾取器的連接。在G級機車上，正電機引線連接到左側軌道拾音器（消防員側）。
導線
斷開通向兩個電機端子的所有導線。請注意，某些電機電刷連接使用彈簧觸點與底盤連接。在這種情況下，也需要拆除或修改彈簧觸點。請注意，某些機車可能僅在重新安裝車身時才會接觸電機和車架。接下來，使用電壓表或連續性測試儀驗證每個電機端子是否與左右導軌拾音器電氣隔離。將儀表設置為歐姆刻度后，將兩個儀表探針一起觸摸，注意儀表指示0歐姆（短路）。您不希望再次看到此指示！將其中一個探針接觸到其中一個電機電刷端子。將另一個探頭接觸機車機架，然后接觸左側軌道電源拾取線，最后接觸右側軌道電源拾取導線。將第一個探針移到另一個電機電刷端子并重復測試。如果所有測試均顯示開路，則電機已正確隔離。在完成此操作之前，不要繼續操作。
Isolate the motor Note this step
Because this is the most important step to successfully convert any locomotive to DCC operation. The two motor brush connections must be electrically isolated so that they are driven only by the DSD motor output. We're not kidding! Digital Sound Decoder User Manual 9 Stop Failure to properly isolate the motor will damage the decoder and turn it into an effective but short-lived smoke generator! Our warranty clearly excludes damage caused by improper motor isolation; However, if you corrupt the decoder, just return it to Throttle Up! Together with the service fee (please indicate the current amount), we will promptly repair and return it. Remove the boiler and bidding shell from the locomotive and bidding frame, and start the motor isolation. Before continuing, it is important to carefully check the locomotive wiring and determine the position and function of each line. The manufacturer's assembly drawing may be useful here, or you can choose to create your own wiring diagram. In particular, you need to identify the connections of the left and right power pickups and the (+) and (-) motor connections. Note: For N, HO, S and O scale locomotives, the positive motor connection is the connection to the right rail (engineer's side) power handler. On Class G locomotives, the positive motor lead is connected to the left track pickup (fireman side).
wireway
Disconnect all wires to both motor terminals. Please note that some motor brush connections use spring contacts to connect to the chassis. In this case, it is also necessary to remove or modify the spring contacts. Please note that some locomotives may only touch the motor and frame when refitting the body. Next, use a voltmeter or continuity tester to verify that each motor terminal is electrically isolated from the left and right rail pickups. After the meter is set to the ohm scale, touch the two meter probes together, and note that the meter indicates 0 ohm (short circuit). You don't want to see this instruction again! Touch one of the probes to one of the motor brush terminals. Contact the other probe with the locomotive frame, then contact the left track power pickup wire, and finally contact the right track power pickup wire. Move the first probe to the other motor brush terminal and repeat the test. If all tests indicate an open circuit, the motor is properly isolated. Do not continue until you have completed this operation.
