電平敏感
PCI中斷外圍組件互連（PCI）本地總線上的中斷是可選的，并定義為“電平敏感”，使用漏極開路輸出驅動器斷言為低（負真）。中斷線INTx#的斷言和反斷言與CLK異步。設備在請求其設備驅動程序注意時斷言其INTx#行。一旦INTx#信號被斷言，它將保持?jǐn)嘌?，直到設備驅動程序清除未決請求。當請求被清除時，設備取消斷言其INTx#信號。PCI為單個功能設備定義了一條中斷線，為多功能設備或連接器定義了多達四條中斷線。對于單功能設備，只能使用INTA#，而其他三條中斷線沒有意義。第47頁的圖2-1描述了與VME操作和PMC站點相關的中斷邏輯。多功能設備上的任何功能都可以連接到任何INTx#線。中斷引腳寄存器定義函數用于請求中斷的INTx#線。如果一個設備實現了一條INTx#線，它被稱為INTA#；如果它實現了兩行，它們被稱為INTA#和INTB#；等等對于多功能設備，所有功能都可以使用相同的INTx#行，或者每個功能都可以有自己的（最多四個功能），或者它們的任意組合。單個函數永遠不能在多個INTx#行上生成中斷請求。
PCI設備中斷映射
從屬PIC通過BIOS定義的線路接受VME中斷。BIOS根據哪個系統需要使用中斷線來定義要使用的中斷線。PCI設備中斷映射基于PCI總線的外部設備包括PMC站點、以太網控制器和PCI到VME橋。默認BIOS將這些外部設備映射到ICH2的PCI中斷請求（PIRQx）線。該映射如圖所示，。無法修改每個設備上存在的設備PCI中斷線（INTA到INTD）。
Level sensitive
PCI Interrupt Interrupts Interrupts on the Peripheral Component Interconnect (PCI) local bus are optional and defined as "level sensitive" and asserted as low (negative true) using an open drain output driver. The assertion and anti assertion of interrupt line INTx # are asynchronous with CLK. The device asserts its INTx # line when requesting its device driver attention. Once the INTx # signal is asserted, it will remain asserted until the device driver clears the pending request. When the request is cleared, the device unasserts its INTx # signal. PCI defines one middle break for a single functional device and up to four middle breaks for a multi-function device or connector. For the single function equipment, only INTA # can be used, while the other three medium line breaks are meaningless. Figure 2-1 on page 47 describes the interrupt logic associated with VME operations and PMC sites. Any function on the multi-function device can be connected to any INTx # line. The interrupt pin register defines the INTx # line whose function is used to request interrupts. If a device implements an INTx # line, it is called INTA #; If it implements two lines, they are called INTA # and INTB #; For multi-function devices, all functions can use the same INTx # line, or each function can have its own (up to four functions), or any combination of them. A single function can never generate an interrupt request on multiple INTx # lines.
PCI device interrupt mapping
The slave PIC accepts VME interrupts through the line defined by the BIOS. The BIOS defines the interrupt line to be used according to which system needs to use the interrupt line. PCI device interrupt mapping PCI bus based external devices include PMC sites, Ethernet controllers, and PCI to VME bridges. The default BIOS maps these external devices to the PCI Interrupt Request (PIRQx) line of ICH2. The mapping is shown in the figure,. The device PCI middle line break (INTA to INTD) present on each device cannot be modified.
產品優勢
1：國外專業的供貨渠道，具有價格優勢
2：產品質量保證，讓您售后無憂
3：全國快遞包郵
4：一對一服務
公司主營范圍簡介
PLC可編程控制器模塊，DCS卡件，ESD系統卡件，振動監測系統卡件，汽輪機控制系統模塊，燃氣發電機備件等，優勢品牌：Allen Bradley、BentlyNevada、ABB、Emerson Ovation、Honeywell DCS、Rockwell ICS Triplex、FOXBORO、Schneider PLC、GE Fanuc、Motorola、HIMA、TRICONEX、Prosoft等各種進口工業零部件、歐美進口模塊。
產品廣泛應用于冶金、石油天然氣、玻璃制造業、鋁業、石油化工、煤礦、造紙印刷、紡織印染、機械、電子制造、汽車制造、塑膠機械、電力、水利、水處理/環保、鍋爐供暖、能源、輸配電等等
