使用說明
繼續軟件描述“04（0x04）讀取輸入寄存器”請求有效寄存器起始地址0有效寄存器數量1響應字節計數2值寄存器輸入狀態位0..3“03（0x03）讀取保持寄存器”請求無效寄存器起始地址0..1或66有效寄存器數量2或1響應功能碼、字節計數、，寄存器值寄存器0：值寄存器1：值寄存器66通信監控的時間常數。寄存器值＝0（0x0000）沒有通信監視，所有其他值用于通信監控，解決方案為10 ms。0x0000至0xFFFF=>0至655.35秒=10.9分鐘位信息0 0=狀態繼電器1關閉1=狀態繼電器2關閉1=通過總線1切換的狀態繼電器2 0=通過手動控制切換的繼電器1 0=通過總線2切換的繼電器2位信息0 0=重置后的初始狀態或通信控制繼電器1關閉1=重置后初始狀態或通訊控制繼電器1 1 0=重置或通訊控制中繼2關閉1=復位后初始狀態，或通信控制中繼2在繼續軟件描述“06（0x06）寫入單寄存器”請求寄存器地址0或1或66寄存器值位0–1根據表或以上請求“16（0x10）寫入多個寄存器”請求有效寄存器起始地址0或1有效寄存器數量1.2字節計數2 x寄存器數量寄存器值數量x 2字節位0–3根據表響應功能代碼、寄存器起始地址
寄存器數量9.2使用Modbus命令奇偶校驗和比特率設置的比特率與通過地址開關設置時的值相同。如果奇偶校驗或位的值為0，則不進行設置或存儲。寄存器內容存儲在EEPROM中?！?6（0x06）寫入單個寄存器”請求有效寄存器地址0x41（65）有效寄存器值2字節位15-8：幻數0x53=83，以防意外寫入。僅使用此編號對命令進行進一步分析。幀請求示例的響應回聲：從地址0x12旋轉開關的設置（18）功能0x06寫入單寄存器地址Hi 0x00寄存器地址Lo 0x41比特率和奇偶校驗（65）寄存器內容Hi 0x53幻數寄存器內容Lo 0x15奇偶校驗偶校驗，19200波特所有設備都可以與廣播命令（從地址0x00）同時切換，建議不要這樣做，因?yàn)檫@可能會導致問題：-其他制造商的設備可能在此地址下有一個用于不同目的的寄存器，然后會以錯誤的方式操作。-沒有來自各個設備的反饋。因此，控制不能立即識別命令是否被正確接收。
instructions
Continue the software description "04 (0x04) Read input register" Request valid register start address 0 Number of valid registers 1 Response byte count 2 Value register input status bit 0.. 3 "03 (0x03) Read holding register" Request invalid register start address 0.. 1 or 66 Number of valid registers 2 or 1 Response function code, byte count, register value register 0: value register 1: value register 66 Time constant for communication monitoring. The register value=0 (0x0000) has no communication monitoring. All other values are used for communication monitoring. The solution is 10 ms. 0x0000 to 0xFFFF=>0 to 655.35 seconds=10.9 minutes bit information 0 0=state relay 1 closed 1=state relay 2 closed 1=state relay 2 switched through bus 1 0=relay 1 switched through manual control 0=relay 2 bit information switched through bus 2 0=initial state after reset or communication control relay 1 closed 1=initial state after reset or communication control relay 1 1 0=reset or communication control relay 2 closed 1=initial state after reset, Or the communication control relay 2 requests the register address 0 or 1 or 66 register value bits 0 – 1 according to the table or the above request "16 (0x10) writing multiple registers" to request the valid register starting address 0 or 1. The number of valid registers is 1.2 bytes count 2 x the number of register values x 2 bytes bits 0 – 3 according to the table to respond to the function code, register starting address
Number of registers 9.2 The bit rate set using the Modbus command parity sum bit rate is the same as the value set through the address switch. If the value of parity or bit is 0, it is not set or stored. The register contents are stored in EEPROM. "06 (0x06) Write to Single Register" requests valid register address 0x41 (65) valid register value 2 byte bits 15-8: magic number 0x53=83 to prevent accidental writing. Use this number only for further analysis of the command. Echo response of frame request example: write single register address Hi 0x00 register address Lo 0x41 bit rate and parity (65) register content Hi 0x53 magic number register content Lo 0x15 parity check from the setting (18) function 0x06 of rotary switch at address 0x12, Because this may cause problems: - Other manufacturers' devices may have a register under this address for different purposes, and then operate in the wrong way- No feedback from each device. Therefore, the control cannot immediately identify whether the command was received correctly.
