CI871K01通信單元
CI871K01通信單元和DC/DC轉換器通過CEX總線從+24 V電源獲得所需電壓。功能和優點通過以太網連接PROFINETIO設備一般信息物品編號3 se056767r1通信協議人員生命周期狀態班集成電路或從控主人變速箱速10/100Mbit/s線路冗余不模塊冗余對熱插拔對與HI控制器一起使用對詳細數據CEX總線上的最大單位12連接器RJ-45內螺紋（8針）24V消耗標準。典型160mA1.數據表CI871 Classic | 2022-10-26 |版權所有?2022 ABBE環境與認證工作55°C防護等級符合EN60529、IEC 529的IP20CE標志對危險場所UL 60079-15，cULus 1級，2區，AEx nA IIC T4，ExnA IIC-T4Gc X海事證書ABS、BV、DNV-GL、LR符合RoHS標準指令/2011/65/EU（EN 50581:2012）WEEE合規性指令/2012/19/EU尺寸寬度59毫米（2.3英寸）身高185毫米（7.3英寸）深度127.5毫米（5.0英寸）重量（包括底座）700克（1.5磅）2.CI871 Classic數據表
CI871K01 communication unit
CI871K01 communication unit and DC/DC converter obtain the required voltage from+24V power supply through CEX bus. Functions and advantages Connect PROFINETIO equipment via Ethernet General information Item No. 3 se056767r1 Communication protocol Personnel life cycle status shift Integrated circuit or slave master gearbox speed 10/100Mbit/s Line redundancy No module redundancy Hot plug pair Used with HI controller Maximum unit 12 connector RJ-45 internal thread (8-pin) 24V consumption standard on CEX bus. Typical 160mA1. Data Sheet CI871 Classic | 2022-10-26 | All rights reserved ? 2022 ABB environment and certification work 55 ° C protection level complies with IP20CE mark of EN60529 and IEC 529. For hazardous places, UL 60079-15, cULus Class 1, Zone 2, AEx nA IIC T4, ExnA IIC-T4Gc X maritime certificates ABS, BV, DNV-GL LR complies with RoHS standard directive/2011/65/EU (EN 50581:2012) WEEE compliance directive/2012/19/EU dimension width 59 mm (2.3 inches) height 185 mm (7.3 inches) depth 127.5 mm (5.0 inches) weight (including base) 700 g (1.5 pounds) 2. CI871 Classic data sheet
