過載瞬態仿真結果
額定穩態長時間運行時，單個IGBT芯片損耗為78.7W，單個Diode芯片損耗為23.4W。過載工況為每個芯片每10min內可允許120% 過載，過載時間為持續1min，允許連續出現過載，即1H內出現6次1.2倍過載。按1.2倍過載，單元輸出電流為356.4A時，單個IGBT芯片損耗為102W，單個Diode芯片損耗為28.9W。
圖8為1.2倍過載瞬態分析中，對IGBT芯片最高溫度的監控曲線。從曲線可以看出，芯片在過載后第60s達到溫升最高值，隨后過載結束溫度下降，在第450s左右，溫度可以降到與穩態時溫度一致。每次瞬態1.2倍過載均不會導致芯片最高溫度有相對升高，說明10min內一次過載1min，有足夠的時間使過載溫度下降到穩態溫度，不會因持續過載導致芯片最高溫度疊加升高。
1.2倍過載瞬態時芯片溫度曲線
1.2倍過載瞬態時芯片溫度曲線
圖8- 1.2倍過載瞬態時芯片溫度曲線
（6）測試數據
熱電偶埋在IGBT銅基板底部，熱電偶通過SatlonD3和催化劑606緊固在散熱器基板上，測試點為仿真溫度最高的IGBT芯片正下方。
IGBT正下方銅基板測試點示意圖01
IGBT正下方銅基板測試點示意圖01
圖9-IGBT正下方銅基板測試點示意圖01
IGBT正下方銅基板測試點示意圖02
IGBT正下方銅基板測試點示意圖02
圖10-IGBT正下方銅基板測試點示意圖02
模塊測試風速按5m/s，與仿真風速一致。測試時環境溫度20℃，測試點1為IGBT模塊的Tc溫度（殼溫），最高值為69℃，溫升49℃。
仿真得到的模塊最高殼溫Tc=86.7℃，溫升為46.7℃。仿真誤差為5%以內，可以接受。說明仿真數據可以評估方案可行性及決定是否需要進行打樣。
熱電偶監測點溫度
熱電偶監測點溫度
圖11-熱電偶監測點溫度
3 結論
對于電力電子設備的散熱設計問題，采用基于FloEFD分析的散熱設計方法能較準確的評估實際工況中的溫度duration of T4. This goes on and on. The time parameters caused by this are all set before leaving the factory. The process flow is as follows:
Use logo! 230rc basic model, because the time of the four time relays given in the flow chart is only set before leaving the factory, it is not equipped with text display LOGO! TD。 Therefore, 230V logo can be used! Of the product.
