The DCS 400 converters of ABB offer the possibility
to have a guided commissioning by means of interactive dialogue through the parameter programming.
One guarantees with it, that the drive is set up right
and is optimized.
This section describes the guided commissioning
with the panel. The necessary dialogue, also Panel
Wizard named, is used by the command sequence
shown below.Parameter entries
The entries required during the guided commissioning procedure are divided into selection parameters
and value parameters.
Selection parameters are selected from a predefined text list and confirmed.
The control panel display only shows one line of this
text list at a time. Therefore, the list must be scrolled
line by line, using the keys. To confirm a
selection, press (17(5 .
Line 1: Parameter number and parameter name.
Line 2: Line currently selected in the text list.
In the commissioning instructions, alternative lines of
a text list are displayed against a grey-shaded background.
Select the desired line using the keys.
Confirm your selection by pressing (17(5 .
Yes/No decisions are treated in the same manner as
selection parameters.
Value parameters are parameters with numerical
contents, whose values can be incremented or decremented by pressing the keys. Each key stroke
will increment or decrement the selected parameter
by 1.
Holding down one of these keys will cause the parameter value concerned to be increased or decreased
rapidly.
Confirm the desired values by pressing (17(5 .
Line 1: Parameter number and parameter name.
Line 2: Parameter value.
During the guided commissioning procedure, all values which can be changed are displayed with an
underline. Use the keys to change the values
and confirm the entry by pressing (17(5 . This will take
you to the next step of the commissioning procedure.
Interrupting the guided commissioning procedure
The guided commissioning procedure can be interrupted by pressing 0(18 . There are three posibilities for
selection for going on the process.
Back to the previous commissioning step.
Continue with the same step.
Exit guided commission procedure.
Confirm your selection by pressing Unexpected trouble during guided commissioning can be eliminated easily. Find
in the following chapters the reason and carry out the measures described there.
For faults, alarms and diagnosis messages,
see chapter 6.4 Troubleshooting.
