無功/功率因數控制觸點輸入（可選）
客戶提供的用于此功能的啟用/禁用觸點連接到標記為52J和52K。只有干燥、不接地的開關觸點應應用于Var/功率因數控制觸點輸入。
并聯發電機補償
客戶提供的用于此功能的啟用/禁用觸點連接到標記為52L和52M。并聯發電機補償只應使用干燥、不接地的開關觸點接觸輸入。
并聯控制和Var/PF控制輸入
端子52L和52M處的用戶提供的觸點確定AVR或下垂模式是否激活。
端子52L和52M通常連接到發電機斷路器的52b輔助觸點。端子52J和52K處的用戶提供觸點控制var或功率因數校正是否激活殘廢端子52J和52K通常連接到公用設施連接斷路器的輔助觸點。桌子4-3列出了不同52L/M和52J/K接觸狀態下實現的操作模式。
封閉狀態指示連續觸點閉合
而開路狀態指示連續開路。電壓匹配（可選）此功能的客戶提供的啟用/禁用觸點連接到標有VM和的端子VMC。只有干燥、不接地的開關觸點應用于電壓匹配觸點輸入。
電壓匹配也通過52J/K和/或52L/M觸點輸入的狀態啟用/禁用。在里面當52J/K或52L/M觸點輸入為打開或僅52J/K觸點輸入打開。電源輸入
電源輸入端子標記為3、4和5?？墒褂脝蜗嗷蛉嚯娫础蜗嚯娫纯蓱?yīng)用于三個端子中的任何兩個。
DECS-100可以直接從各種電源供電，只要DECS-100INPUT電源規范（見第1節，一般信息，規范）。
DECS-100操作電源的示例包括：?發電機（并聯供電）
永磁發電機（PMG）
?輔助繞組
當從低阻抗電源向DECS-100供電時，必須作出特殊規定：避免損壞DECS-100。低阻抗電源的示例包括電站服務電源或電源插座。浪涌電流降低模塊ICRM-7必須連接在電源和DECS-100輸入電源端子（見圖4-10）。ICRM-7防止DECS-100通過最大限度地降低浪涌電流水平造成的損壞。ICRM-7也可用于編程DECS-100。但是，初步設置段落說明了臨時為DECS-100提供編程電源。有關ICRM-7的更多詳細信息，請參見Basler Electric出版物9387900990。
Voltage Matching (Optional) A customer-supplied enable/disable contact for this function connects to the terminals labeled VM and VMC. Only dry, ungrounded switching contacts should be applied to the Voltage Matching contact input. Voltage matching is also enabled/disabled by the state of the 52J/K and/or 52L/M contact inputs. In BESTCOMS, voltage matching can be configured to be disabled when the 52J/K or 52L/M contact input is open or just the 52J/K contact input is open. Power Supply Inputs Power input terminals are labeled 3, 4, and 5. Single-phase or three-phase power may be applied. Singlephase power may be applied to any two of the three terminals. The DECS-100 can be powered directly from a variety of sources as long as the DECS-100 input power specifications are followed (see Section 1, General Information, Specifications). Examples of DECS-100 operating power sources are: ? Generator (shunt fed) ? Permanent magnet generator (PMG) ? Auxiliary winding When powering the DECS-100 from a low-impedance power source, special provisions must be made to avoid damage to the DECS-100. Examples of a low-impedance power source include a station service source or power outlet. An Inrush Current Reduction Module, ICRM-7, must be connected between the power source and DECS-100 input power terminals (see Figure 4-10). The ICRM-7 prevents DECS-100 damage by minimizing the level of inrush current. The ICRM-7 can also be used when programming the DECS-100. However, the Preliminary Setup paragraphs illustrate an alternate method for temporarily powering the DECS-100 for programming. More details about the ICRM-7 are available in Basler Electric publication 9387900990.
