SK827005交流接觸器
無功下垂補償
DECS-100提供無功下垂補償功能，以幫助分擔無功負載在并聯發電機運行期間。當該功能啟用時，DECS-100計算無功使用感應到的發電機輸出電壓和電流量的發電機負載部分，然后相應地修改電壓調節設定點。單位功率因數發電機負載導致：發電機輸出電壓無變化。滯后功率因數發電機負載（感應）導致發電機輸出電壓降低。領先功率因數發電機負載（電容性）導致發電機輸出電壓增加。額定、標稱B相時，下垂可調高達10%線路電流（通過端子CT1和CT2施加的1安培或5安培）和0.8功率因數。這個通過并聯發電機補償觸點輸入電路啟用和禁用下垂特性（端子52L和52M）。在var或功率因數控制模式下運行時，下垂也被禁用。
低頻當發電機頻率下降到所選拐點頻率設定值以下時，電壓設定值為由DECS-100自動調整，使發電機電壓遵循選定的PU（每單位）V/Hz曲線在選定的PU V/Hz曲線上運行時，低頻激活指示燈亮起前面板和BESTCOMS。低于12赫茲時禁用欠頻控制。膝關節頻率為以0.1赫茲增量從40赫茲到65赫茲可調，且PU V/Hz曲線的斜率可設置為0通過BESTCOMS軟件在0.01步中設置為3。斜率為0將有效禁用欠頻作用DECS-100的最小調節點約為標稱值的30%設定點。保護DECS-100包括三種保護功能：發電機過壓、傳感電壓損失和磁場過電壓。每個保護功能都有一個相應的前面板指示燈，當功能處于活動狀態。主動保護功能也通過BESTCOMS通知。
發電機過電壓
發電機過電壓條件可配置為（在BESTCOMS中）關閉DECS-100繼電器輸出、禁用DECS-100、啟動兩個動作或不啟動任何動作。當感測到發電機在可調報警時間內，電壓升高超過可調電壓電平設定值DECS-100啟動所選動作。
如果DECS-100配置為關閉繼電器輸出，發電機過電壓條件將點亮前面板和BESTCOMS發電機過壓指示器，并關閉端子AL1處的繼電器輸出和AL2。
如果DECS-100配置為硬件關機，發電機過電壓條件將禁用報警時間延遲到期后的DECS-100。當發電機后DECS-100通電時過電壓停機時，發電機過電壓指示燈將點亮5秒鐘。
電壓電平設定值可在系統電壓設定值的100%至120%之間調整。報警時間延遲可從0到10秒進行調整。
Reactive Droop Compensation
The DECS-100 provides a reactive droop compensation feature to assist in the sharing of reactive load
during parallel generator operation. When this feature is enabled, the DECS-100 calculates the reactive
portion of the generator load using the sensed generator output voltage and current quantities and then
modifies the voltage regulation setpoint accordingly. A unity power factor generator load results in almost
no change in generator output voltage. A lagging power factor generator load (inductive) results in a
reduction of generator output voltage. A leading power factor generator load (capacitive) results in an
increase of generator output voltage. Droop is adjustable up to 10 percent with rated, nominal B-phase
line current (1 ampere or 5 amperes applied through terminals CT1 and CT2) and 0.8 power factor. The
droop feature is enabled and disabled through the Parallel Generator Compensation contact input circuit
(terminals 52L and 52M). Droop is also disabled when operating in var or power factor control modes.
Underfrequency
When generator frequency drops below the selected knee frequency setpoint, the voltage setpoint is
automatically adjusted by the DECS-100 so that generator voltage follows the selected PU (per unit) V/Hz
curve. When operating on the selected PU V/Hz curve, the Underfrequency Active indicator lights on the
front panel and in BESTCOMS. Underfrequency control is disabled below 12 hertz. The knee frequency is
adjustable from 40 to 65 hertz in 0.1 hertz increments and the PU V/Hz curve may be set at a slope of 0
to 3 in 0.01 steps through BESTCOMS software. A slope of 0 effectively disables the underfrequency
function. The DECS-100 has a minimum regulation point of approximately 30 percent of the nominal
setpoint. Protection
The DECS-100 includes three protective functions: generator overvoltage, loss of sensing voltage, and
field overvoltage. Each protective function has a corresponding front panel indicator that lights when the
function is active. An active protective function is also annunciated through BESTCOMS.
Generator Overvoltage
A generator overvoltage condition can be configured (in BESTCOMS) to close the DECS-100 relay
output, disable the DECS-100, initiate both actions, or initiate neither action. When the sensed generator
voltage increases above the adjustable voltage level setpoint for the duration of the adjustable alarm time
delay, the DECS-100 initiates the selected action.
If the DECS-100 is configured to close the relay output, a generator overvoltage condition will light the
front panel and BESTCOMS Generator Overvoltage indicator and close the relay output at terminals AL1
and AL2.
If the DECS-100 is configured for hardware shutdown, a generator overvoltage condition will disable the
DECS-100 after the alarm time delay expires. When the DECS-100 is powered up following a generator
overvoltage shutdown, the Generator Overvoltage indicator will light for five seconds.
The voltage level setpoint is adjustable from 100 to 120 % of the system voltage setting. The alarm time
delay is adjustable from 0 to 10 seconds.
