DSDP170通信模塊
本章介紹了檢查系統狀態的機制：系統故障觸點。使用程序中的這些預定義聯系人檢查：特定故障，如系統配置不匹配、機架丟失或總線故障。
故障/無故障點觸點。使用這些觸點監控單個、離散和模擬點的故障或缺乏故障狀態。
故障/無故障用戶觸點。使用這些聯系人可監視的狀態FIP網絡上的設備。
報警觸點：使用這些觸點監控模擬參考是否：達到其報警上限或下限。
故障表：PLC的故障表提供了更廣泛的系統操作視圖，以及幫助指示多個故障和報警之間的因果關系。
總線控制器和信道狀態位：使用這80個狀態位監控操作總線控制器和兩條總線，并監控多達32TCP/IP通信信道。附加診斷
本章描述了FIP總線控制器對網絡故障的正常記錄
第8章解釋了網絡故障信息如何存儲在選定區域中以及如何將某些網絡故障記錄到PLC故障表中
殘廢系統故障觸點在%S內存中有預定義的昵稱和位置。他們可以包括在應用程序中以檢查故障相關條件。以下系統故障觸點對于具有FIP總線控制器的系統特別重要：PLC系統包括一個總線控制器。在CPU配置期間，系統狀態故障LOS_IOC已被指定為診斷（而非致命）故障。LOS_ IOC表示總線控制器的丟失；如果發生這種情況，IOC故障的損失將被置于I/O故障表。在本例中，應用程序還監控LOS_IOC
參考如果設置了該參考，則觸點將功率流傳遞到輸出線圈，輸出線圈使操作員面板上的警告燈通電。故障和無故障觸點可用于檢測系統上的故障或缺少故障條件離散（%I）或模擬（%AI）參考。
故障觸點[故障]將檢測離散或模擬輸入或輸出中的故障，或系統的硬件組件。如果參考有以下情況，則觸點通過功率流：錯誤。故障和無故障觸點由來自輸入模塊。如果無法使用驗證器信息，例如設備失去電源或網絡連接，或數據未刷新或未激活，故障觸點將由FIP總線控制器設置。如果未配置驗證程序信息對于消耗，永遠不會設置故障觸點。
This chapter describes mechanisms for checking the status of the system:
System Fault Contacts. Use these predefined contacts in the program to check for
specific faults such as System Configuration Mismatch, Loss of Rack, or Bus faults.
Fault/No Fault Point Contacts. Use these contacts to monitor individual discrete and
analog points for their fault or lack of fault status.
Fault/No Fault Subscriber Contacts. Use these contacts to monitor the status of
devices on the FIP network.
Alarm Contacts: Use these contacts to monitor whether analog references have
reached their upper or lower alarm limits.
Fault Table: the PLC’s fault tables provide a broader view of system operations and
help indicate causal relationships among multiple faults and alarms.
Bus Controller and Channel Status Bits: Use these 80 status bits to monitor the
operation of the Bus Controller and two busses and to monitor the status of up to 32
TCP/IP communications channels.
Additional Diagnostics
This chapter describes normal logging of network faults by the FIP Bus Controller.
Chapter 8 explains how network fault information can also be stored in a selected area
of PLC memory, and how logging certain network faults into the PLC fault table can be
disabled.System fault contacts have pre-defined nicknames and locations in %S memory. They
can be included in an application program to check for fault-related conditions. The following system fault contacts are of special interest for a system with a FIP Bus Controller:A PLC system includes one Bus Controller. During CPU configuration, the system status
fault LOS_IOC has been designated a diagnostic (rather than fatal) fault. LOS_IOC represents loss of the Bus Controller; if this occurs, the Loss of IOC fault will be placed in the
I/O Fault Table. In this example, the application program also monitors the LOS_IOC
reference. If this reference is set, the contact passes power flow to an output coil, which
energizes a warning light on an operator panel.Fault and No Fault contacts can be used to detect fault or lack of fault conditions on a
discrete (%I) or analog (%AI) reference.
A Fault contact [FAULT] will detect a fault in a discrete or analog input or output, or a
hardware component of the system. The contact passes power flow if the reference has
a fault.Fault and No Fault contacts are driven by consumption of validator information from the
input module. If the validator information cannot be consumed, for example, if a remote
device loses power or network connection, or data is unrefreshed or unprompt, the Fault
contacts will be set by the FIP Bus Controller. If no validator information is configured
for consumption, the Fault contact will never be set.
