AO810V2模擬量輸入模塊
參數“DefDirMode”決定了最后的響應確定的時間。它可以設置為任意方向（在跳閘方向）或非方向（見圖3.5.31.8）。
注：即使使用過電流，仍有一個確定的區域
啟動器（OC），但僅與參數延遲有關（Def）和“DefDirMode”。
3.5.31.5.備用過電流裝置（O/C備用保護）（見第4.8.4節。）
備用過電流裝置的設置通過“O/C備用保護”子菜單。的設置
參數“I O/C”確定拾取級別，可以是在0.1英寸到10英寸之間的步驟中選擇。關聯
通過以下方式將時間延遲設置為0.1秒，介于0和10秒之間：參數“延遲O/C”。過電流裝置的拾取信號也用于存根保護。如果該功能用于此目的，i、 e.二進制i/P“隔離開關打開”處于邏輯“1”，跳閘時間為固定在25ms。3.5.31.6.V.t.監督（見第4.8.3節。）
設置v.t.監控功能的參數位于子菜單“v.t.SUPERVISON”中?？梢允褂谩癡TSupMode”選擇四種不同的操作模式之一。
這個函數處理零序和負序分量
它們要么單獨使用（“零序列”和“負序列”），要么組合（“零*NegSeq”和“Spec”）。四個拾取值是參數的設置“U0min VTSup”、“U2min Vtsop”、“I0min VTSup”和“I2min VTSup”。
它們可以在0.01的步驟中設置在0和2 UN（或IN）之間
電壓的基本設置為0.2 UN，電壓為0.07 IN
現在的只有“NegSeq”或“Spec”選項不接地系統。
運行時，通常需要v.t.監督功能要立即阻止距離保護功能（請參閱第4.8.5.2節）。但是，為阻止
通過設置參數，延遲12秒后的距離函數“VTSupBlkDel”。該參數通常在以下情況下設置：
僅使用過電流啟動器。如果v.t.監控功能保持啟動的時間超過12秒，它僅在延遲（1s）后復位。錯誤是否會導致零序或負序電流分量，立即復位。
參數“VTSupDebDel”（解塊）啟用重置無論電流如何，延遲將持續啟用。
The parameter ‘DefDirMode’ determines the response at the end
of the definitive time. It can be set to be either directional (in
tripping direction) or non-directional (see Fig. 3.5.31.8).
Note:
There is still a definitive zone even using the overcurrent
starter (OC), but only with respect to the parameters ‘Delay
(Def)’ and ‘DefDirMode’.
3.5.31.5. Back-up overcurrent unit
(O/C Back-up Protection)
(see Section 4.8.4.)
The settings for the back-up overcurrent unit are made via the
sub-menu ‘O/C BACK-UP PROTECTION’. The setting of the
parameter ‘I O/C’ determines the pick-up level, which can be
chosen in steps of 0.1 IN between 0 and 10 IN. The associated
time delay is set in steps of 0.1 s between 0 and 10 s by means
of the parameter ‘Delay O/C’.The pick-up signal of the overcurrent unit is also used by the
STUB protection. If the function is being used for this purpose,
i.e. the binary I/P ‘Isol open’ is at logical ‘1’, the tripping time is
fixed at 25 ms.
3.5.31.6. V.t. supervision
(see Section 4.8.3.)
The parameters for setting the v.t. supervision function are located in the sub-menu ‘V.T. SUPERVISON’. One of four different operating modes can be chosen using ‘VTSupMode’. The
function processes zero and negative-sequence components,
which are either used on their own ('ZeroSeq’ and ‘NegSeq') or
combined ('Zero*NegSeq’ and ‘Spec').The four pick-up values are the settings of the parameters
‘U0min VTSup’, ‘U2min VTSup’, ‘I0min VTSup’ and ‘I2min VTSup’.
They can be set between 0 and 2 UN (or IN) in steps of 0.01. The
basic settings are 0.2 UN for the voltage and 0.07 IN for the
current.
Only the ‘NegSeq’ or ‘Spec’ options are available in ungrounded
systems.
Upon operating, the v.t. supervision function is normally required
to immediately block the distance protection function (see
Section 4.8.5.2.). Provision is made, however, for blocking the
distance function after a delay of 12 s by setting the parameter
‘VTSupBlkDel’. This parameter is normally set in cases where
only the overcurrent starters are in use.If the v.t. supervision function remains picked up for longer than
12 s, it resets only after a delay (1 s). Should a fault give rise to
zero or negative-sequence current components, it resets immediately.
The parameter ‘VTSupDebDel’ (deblocking) enables the reset
delay to be continuously enabled regardless of current.
