交直流電源裝置8.1電源裝置的類型
有兩種類型的交流至直流電源裝置：
a、 8路交流至直流電源裝置（零件號05701-a-0406）
1U高半寬19英寸機架安裝單元，包含單個50W開關模式AC到DC電源模塊。
b、 16路交流至直流電源裝置（零件號05701-A-0405）1U高19英寸機架安裝單元，包含單個50W
開關模式AC到DC電源模塊。
兩個電源裝置將在85V至264V、47Hz至
440Hz交流電源或110V至340V直流電源（參見齊薇格直流電源信息的分析）。
8.2電源單元升級
兩個電源單元均配有內部連接，以：通過添加第二個50W，將功率升級到100W
開關模式AC到DC電源模塊（零件號05701-A-0440）。
第二個子單元（零件號05701-A-0441）可以安裝到
基本16路電源裝置，如果需要超過100W，則：操作系統。附加子單元將包含一個50W開關
模式AC至DC電源模塊為標準，因此提供額外的50W可用功率。如果需要，再增加50W
開關模式AC到DC電源模塊（零件號05701-A-0440）可添加到該第二子單元，以提供電力
可用性敢達200W。
使用的開關電源模塊完全過載被保護并且被設計為連接在一起。
8.3電源連接
輸入交流電源通過位于的三芯電纜連接
每個單元的后部。
標稱24V直流輸出電源通過雙芯電纜連接
在每個單元的后部。
50W子單元配有一個50W開關模式AC至DC
電源模塊如下所示：
此類裝置在標識標簽上標識如下：
電源單元05700-A-0405 Iss。2.
輸入=85-264V交流輸出=24V直流
47-440Hz功率=50W或110-340V DC=100W
表明50W機組頂視圖50W切換模式交直流電源供應模塊額外50W開關式交流至直流電源單元
8.7 100W子單元布局
100W子單元是一個50W子單元，帶有一個額外的50W開關
模式AC至DC電源模塊安裝
AC TO DC POWER SUPPLY UNITS
8.1 Types of Power Supply Unit
There are two types of AC to DC power supply units:
a. 8-Way AC to DC Power Supply Unit (Part Number 05701-A-0406)
A 1U high half width 19 inch rack mounted unit that contains a
single 50W Switched Mode AC to DC Power Supply Module.
b. 16-Way AC to DC Power Supply Unit (Part Number 05701-A-0405)
A 1U high 19 inch rack mounted unit that contains a single 50W
Switched Mode AC to DC Power Supply Module.
Both power supply units will operate from an 85V to 264V, 47Hz to
440Hz ac supply, or a 110V to 340V dc supply (Refer to Zellweger
Analytics for information on dc supplies).
8.2 Power Supply Unit Upgrades
Both power supply units are provided with internal connections to
enable a power upgrade to 100W by the addition of a second 50W
Switched Mode AC to DC Power Supply Module (Part Number 05701-
A-0440).
A second sub-unit (Part Number 05701-A-0441) can be fitted to the
basic 16-way power supply unit if more than 100W is required to
operate the system. The additional sub-unit will contain a 50W Switched
Mode AC to DC Power Supply Module as standard and will therefore
give an additional 50W of available power. If required a further 50W
Switched Mode AC to DC Power Supply Module (Part Number 05701-
A-0440) can be added to this second sub-unit to bring the power
availability up to 200W.
The switched mode power supply modules used are fully overload
protected and are designed to be connected together.
8.3 Power Supply Connections
The input ac power supply is connected via a three core cable at the
rear of each unit.
The nominal 24V dc output supply is connected via a twin core cable
at the rear of each unit.
The 50W Sub-unit is fitted with a single 50W Switched Mode AC to DC
Power Supply Module as shown below:
This type of unit is identified on the identification label as follows:
POWER SUPPLY UNIT 05700-A-0405 Iss. 2
INPUT = 85 - 264V AC OUTPUT = 24V DC
47 - 440Hz POWER = 50W
OR 110 - 340V DC = 100W
Indicates
50W Unit
Top View 50W Switched Mode
AC to DC Power
Supply Module
Additional 50W
Switched Mode AC
to DC Power Supply
Module
8.7 100W Sub-Unit Layout
The 100W Sub-unit is a 50W Sub-unit with an additional 50W Switched
Mode AC to DC Power Supply Module fitted as shown below:
