3BHB004027R0101高壓變頻模塊,GVC700AE01說明書文檔
輸入電壓可以有+25%/-30%的變化，在100ms內下降至標稱電壓的60%或上升至140%，但不可以有 “功能偏差”， 或是在一秒內，輸入電壓從標稱電壓的125%升至140%而導致性能下降的情況。為了應對這些變化，110V系統的DC/DC轉換器通常必須在43VDC至160VDC之間工作。
3BHB004027R0101高壓變頻模塊,GVC700AE01說明書文檔系統電源軌上也會出現EN 61000-4-x標準中定義的快速瞬態過電壓，簡單的抑制器和LC濾波器就可以減弱這些過電壓，但也有可能造成徹底斷電。EN 50155定義了S1和S2兩種斷電等級，最嚴重的是標稱輸入電壓中斷10ms，但不會對電源性能造成影響。對于某些設備來說，電源轉換（Class C2）造成的中斷可長達30ms。為了解決這個問題，常見的方法是在隔離串聯二極管之后斷電維持電容，該二極管還可以提供反極性保護，這也是標準中的另一項要求。
應用范例如圖1所示，其中，風扇由車廂溫度傳感器激活，并通過WLAN發出溫度和狀態信號。圖示中RECOM 8W DC/DC轉換器的輸入范圍為43V至160V，可為傳感器電路提供5V隔離的穩壓電源軌。轉換器尺寸緊湊，僅32 x 20 x 10mm。RECOM DC/DC轉換器符合EN50121-3-2對鐵路車輛EMC標準的要求，除此之外，延長的保持時間、反極性保護以及EMI濾波器的可選性，讓轉換器對瞬態和低頻傳導干擾具有較高的抵抗力。鐵路用DC/DC轉換器有時需要符合UK RIA 12標準，該標準定義了110V系統在20ms內最高浪涌電壓可達385V。但是在電源輸入阻抗僅為0.2歐姆的情況下，用瞬態電壓抑制器抑制輸入電壓會消耗過多電能。RECOM的解決方案是使用RSPxx-168前端瞬態電壓抑制器（圖2），將浪涌電壓降至DC/DC轉換器輸入電壓范圍內的最大值，為DC/DC轉換器提供浪涌保護。RECOM提供20W、150W和300W三種瞬態保護模塊可供選擇。集中式鐵路車輛系統和軌道裝置也需要更高功率的轉換器。RECOM的RPxxx-RW和RPxxxRUW系列“磚”型DC/DC轉換器很受市場歡迎，模塊具有12:1輸入電壓范圍，涵蓋了從24VDC至110VDC的所有鐵路標準輸入電壓，并且涵蓋了輸入浪涌和欠壓。DIN導軌型也是常見應用，例如RECOM的姊妹公司Power Control Systems（PCS）提供堅固耐用的120W SQ120模塊，輸入為110VDC，符合EN50155標準。
After the capacity expansion of the whole system, its performance parameters will not be reduced;
6) The rated voltage is available in 400V and 690V, and the rated capacity can be combined arbitrarily from 200KVA to 3000kva;
7) It has strong overload capacity. In view of the possible reverse power and reactive power interaction at the moment of connecting the ship to the grid, through hardware design and software design, it can effectively suppress various impact conditions in the process of connecting the grid, so that the success rate of connecting the ship can reach 100%;
8) Automatic voltage stabilization function, when the power grid voltage fluctuates, through the internal PID closed-loop control, the output power grid does not fluctuate with the power grid fluctuation and does not change with the load fluctuation;
9) There are two ways to connect ships: active ship connection and passive ship connection, which are suitable for all kinds of ships' shore power needs;
10) The sb70p series shore power supply control system is customized and developed for the customer's needs of shore power supply to meet the power supply requirements of shore power supply system. In the field of building automation, the extensive use of power supply is often accompanied by strict technical requirements. The application environment of power supply in buildings is usually very bad. Thunderstorms can cause strong transients in power supply voltage, especially in high-rise and tower buildings. Therefore, the robust electrical design of power input converter is very important. In extreme cases, surge protectors are also used to protect the power input.
