3BSC980004R784工控卡件，DATX110數據庫
實現線損精細化、標準化管理，進一步計算大用戶供電中電網公司網損，從而確定配電成本及過網費形成價格機制，進而全面提高電網可靠、經濟運行水平。
本地地調已建成地調電量采集主站系統，并上線運行，具備接入用戶關口表表碼上傳的接入條件。供電公司調控中心要求各并網火電廠、風電場、水電廠、用戶變電站投資建設一套電量采集終端，采用IEC60870-5-102通信協議，通過調度數據網非實時通道將關口表表碼上傳至地調電量采集主站系統。再由地調轉發至蒙東省調網損在線計算分析系統。
3BSC980004R784工控卡件，DATX110數據庫為滿足本地地調建設電量采集系統的相關要求，針對公司現有關口電量上傳現狀，對現有設備作了技術改造，最終實現電能數據成功上傳地調，滿足了供電公司建設電量采集系統的要求。
2 現有數據網及電量上傳現狀
公司現有電力調度數據網已建成投運，具備實時通道和非實時通道，現有總調相關遙測、遙信數據通過實時通道將浮點值上傳至地調，非實時通道處于空閑狀態，即只要有電度數據接入，即可通過該通道將準實時電度數據上傳地調電量采集主站系統。
現有電力調度數據網示意圖見下圖1。
按地調要求，需要接入的電量數據有總降進線、發電機出線等，目前公司總降進線、發電機出線、熱電出線電度表RS—485通信口接線示意圖，見下圖2。
圖2中，每塊電度表有兩個RS—585通信口，分別被綜合自動化系統、iES—E50電能量遠方終端、無線雙向終端占用：電度表3、4、5、6、7、8、9、10通信口1及電度表1、2通信口2通過屏蔽RS485通信線連接綜合自動化系統前置機MOXA串口15通信（DLT-645規約），電度表3、4、5、6、7、8、9、10通信口2及電度表1、2通信口1與iES—E50電能量遠方終端通信，電能量遠方終端通過撥號方式連接PCM設備、傳輸設備與電業局計量中心計量主站系統通信。
3 電量采集系統的建設方案debugging function has won the unanimous praise of users, and once again has withstood a strict test in an extremely complex industrial environment. In the hulusu coal washing plant project, the NA400 PLC adopts the distributed structure of Ethernet Remote i/o. The PLC master station is set in the substation of the electrical test building, the PLC substation is set in the distribution room of the concentration workshop, the raw coal bunker substation and the product bunker substation, and the PLC upper computer is set in the centralized control room of the electrical test building. The communication between PLC master station and PLC substation, between PLC and upper computer is through industrial Ethernet, and between PLC and intelligent equipment is through industrial bus. The control and communication interfaces with gas monitoring system, rapid loading station and olefin project are considered, and the reserved interfaces with large chemical fertilizer projects are reserved. S908 optical fiber networking is used between PLC master station and slave station i/o, and Ethernet switch networking is used between master station PLC and control room Project Overview: there are 2 main stations +1 i/o in the semi autogenous grinding electrical building, 1 i/o in the substation, 2 main stations +1
