創建分區方案后，可以將分區格式化為包含所需的文件系統。如前所述，典型系統由VMIVME-7750及其駐留系統組成配置為輔助IDE設備的閃存，連接到主IDE接口，以及連接到軟盤接口的軟盤驅動器。使用這種配置，可能需要在任一IDE上都有一個邏輯設備設備，配置為可引導設備，允許選擇第一個引導設備通過先進的CMOS設置屏幕。使用此功能，用戶可以配置有多個操作系統的系統，可以通過以下方式進行選擇：將IDE邏輯設備指定為引導設備。
UFC760BE41控制卡DOS實用程序FDISK通常用于配置硬盤驅動器。下一頁的評論與使用FDISK。注意：刪除分區將刪除以前存儲在該分區中的所有數據隔斷閃存盤將配置為從工廠以下示例序列說明了創建兩個8 MB分區，其中一個作為活動主分區。注意退出FDISK的說明。這已被證明是成功的分區工作。
1、接通VMIVME-7750電源，進入CMOS設置。
2、將IDE硬盤主機設置為“未安裝”。3、將閃存盤主機設置為“自動”。
4、將引導設備設置為軟盤。
5.從軟盤引導DOS，并驗證系統配置屏幕僅顯示閃存盤。
6、運行FDISK。
7.刪除所有當前分區（當前存儲在分區中的任何數據都將被刪除丟失）。
8.退出FDISK（這將導致重新啟動），然后再次運行FDISK。9.創建一個8MB的主分區。
10.創建一個8兆字節的擴展分區。
11.為8 MB擴展分區設置邏輯設備。
12、將主分區設置為活動分區。
13、退出FDISK。
Following the creation of the partitioning scheme, the partitions can be formatted to
contain the desired file system.
As discussed earlier, a typical system consists of the VMIVME-7750 with its resident
Flash Disk configured as the Secondary IDE device, a hard drive attached to the
Primary IDE interface, and a floppy drive attached to the floppy interface.
Using this configuration, it may be desirable to have a logical device on either IDE
device, configured as a bootable device, allowing the selection of the first boot device
by way of the Advanced CMOS Setup screen. Using this capability, a user could have
a system configured with multiple operating systems that would be selectable by
assigning the IDE logical device as the boot device.
The DOS utility FDISK is commonly used to configure the partition structure on a
hard drive. Comments on the following page pertain to partitioning efforts using
FDISK.
CAUTION: Deleting a partition will erase all the data previously stored in that
partition.
The Flash Disk will be configured as a single partition device as delivered from the
factory. The following sample sequence illustrates a proven method for creating two
8 Mbyte partitions, with one as an active primary partition. Take note of the
instructions to exit FDISK. This has been shown to be an important step in a
successful partitioning effort.
1. Power up the VMIVME-7750 and enter the CMOS set-up.
2. Set IDE HDD Master to “Not Installed”. 3. Set Flash Disk Master to “AUTO”.
4. Set boot device to floppy.
5. Boot DOS from the floppy, and verify that the System Configuration Screen
shows only the Flash Disk.
6. Run FDISK.
7. Delete all current partitions (any data currently stored in the partitions will be
lost).
8. Exit FDISK (this will cause a reboot), then run FDISK again.
9. Create an 8 Mbyte primary partition.
10. Create an 8 Mbyte extended partition.
11. Set-up a logical device for the 8 Mbyte extended partition.
12. Set the Primary partition as an active partition.
13. Exit FDISK.
