Support for SRTP Channels, Modbus/TCP Server, and Modbus/TCP Client
? Full programming and configuration services
? Comprehensive station management and diagnostic tools
? Two full-duplex 10BaseT/100BaseT/TX (RJ-45 Connector) ports with an internal network
switch providing auto-negotiated network speed, duplex mode, and crossover detection.
? User-configurable Redundant IP address
? Time synchronization to SNTP time server on Ethernet network (when used with Release
5.00 or later CPU module).Specifications
Note: For environmental specifications and compliance to standards (for example, FCC or European Union Directives),
refer to Appendix A of the PACSystems RX7i Installation Manual, GFK-2223.
Battery: Memory retention For battery selection, installation and estimated life, refer to the
PACSystems Controller Battery and Energy Pack Manual, GFK-2741.
Program storage Up to 64 Mbytes of battery-backed RAM
64 Mbytes of non-volatile flash user memory
Power requirements: CPE030
CPE040
+5 VDC: 3.2 Amps nominal
+12 VDC: 0.003 Amps nominal
-12 VDC: 0.003 Amps nominal
+5 VDC: 6.8 Amps nominal
+12 VDC: 0.003 Amps nominal
-12 VDC: 0.003 Amps nominal
Operating temperature: CPE030
CPE040
0 to 50°C (32°F to 122°F)
0 to 60°C (32°F to 140°F) with fan tray
0 to 60°C (32°F to 140°F), fan tray required
Boolean execution speed, typical: CPE030
CPE040
0.069ms per 1000 Boolean contacts/coils
0.02391ms per 1000 Boolean contacts/coils
Time of Day Clock accuracy Maximum drift of ±2 seconds per day
Elapsed Time Clock (internal timing) accuracy ±0.01% maximum
Embedded communications RS-232, RS-485, Ethernet interface
Serial Protocols supported Modbus RTU Slave, SNP, Serial I/O
Ethernet Ports Embedded auto-sensing 10/100 Mbps half/full duplex Ethernet
interface
VME Compatibility System designed to support the VME64 standard ANSI/VITA 1
