每個接口支持CT、DCD、RTS和DTR控制信號，如以及TxD和RxD發送/接收數據信號，以及TxC/RxC同步時鐘信號。因?yàn)椴⒎撬姓{(diào)制解調器控制線都可用在Z85230中，Z8536 CIO用于提供缺失的調制解調器線路。PAL設備執行寄存器訪問和偽中斷的解碼在ISA輸入/輸出空間中確認Z85230和Z8536的周期。這個PIB控制器為Z85230提供DMA支持。Z85230接收10 MHz時鐘輸入。Z85230提供偽中斷確認周期期間的中斷向量。
3BDH000013R1主控板向量是根據中斷源在Z85230內修改。打斷請求級別通過PIB控制器編程。參見Z85230數據表和MVME2600/2700系列單板計算機程序員參考指南，了解更多信息。Z8536 CIO設備Z8536 CIO設備通過提供Z85230 ESCC未提供調制解調器控制線路。此外Z8536 CIO設備有三個獨立的16位計數器/計時器。這個Z85230接收5 MHz時鐘輸入。基本模塊特征寄存器基本模塊功能寄存器包含MVME2700的詳細信息單板計算機的配置。它是一個8位只讀寄存器位于ISA輸入/輸出地址$0802的基板上。SCCP? Z85230 ESCC存在。如果設置，則無車載同步串行支持（不存在ESCC）。如果已清除，安裝了Z85230 ESCC，并且有車載支持同步串行通信。PMC2P? PMC/PMCIX插槽2存在。如果設置，則沒有PCI夾層卡（或PCI擴展設備）安裝在PMC插槽2中。如果清除，PMC/PMCIX插槽2包含PCI夾層卡（或PCI擴展設備）。PMC1P? PMC插槽1存在。如果設置，則未安裝PCI夾層卡在PMC插槽1中。如果清除，PMC插槽1包含PCI夾層卡。VMEP? VMEbus存在。如果設置，則沒有VMEbus接口。如果清除后，支持VMEbus接口。LANP? 存在以太網。如果設置，則不需要以太網收發器接口安裝。如果清除，則有車載以太網支持。SCSIP? SCSI存在。如果設置，則沒有板載SCSI接口。如果已清除，支持板載SCSI。
Each interface supports the CTS, DCD, RTS, and DTR control signals as
well as the TxD and RxD transmit/receive data signals, and TxC/RxC
synchronous clock signals. Since not all modem control lines are available
in the Z85230, a Z8536 CIO is used to provide the missing modem lines.
A PAL device performs decoding of register accesses and pseudo interrupt
acknowledge cycles for the Z85230 and the Z8536 in ISA I/O space. The
PIB controller supplies DMA support for the Z85230.The Z85230 receives a 10 MHz clock input. The Z85230 supplies an
interrupt vector during pseudo interrupt acknowledge cycles. The vector is
modified within the Z85230 according to the interrupt source. Interrupt
request levels are programmed via the PIB controller. Refer to the Z85230
data sheet and to the MVME2600/2700 Series Single Board Computer
Programmer’s Reference Guide for further information.
Z8536 CIO Device
The Z8536 CIO device complements the Z85230 ESCC by supplying
modem control lines not provided by the Z85230 ESCC. In addition, the
Z8536 CIO device has three independent 16-bit counters/ timers. The
Z85230 receives a 5 MHz clock input.
Base Module Feature Register
The Base Module Feature Register contains the details of the MVME2700
single board computer’s configuration. It is an 8-bit read-only register
located on the base board at ISA I/O address $0802.SCCP? Z85230 ESCC present. If set, there is no on-board
synchronous serial support (the ESCC is not present). If
cleared, the Z85230 ESCC is installed and there is on-board
support for synchronous serial communication.
PMC2P? PMC/PMCIX slot 2 present. If set, no PCI mezzanine card (or
PCI expansion device) is installed in PMC slot 2. If cleared,
PMC/PMCIX slot 2 contains a PCI mezzanine card (or PCI
expansion device).
PMC1P? PMC slot 1 present. If set, no PCI mezzanine card is installed
in PMC slot 1. If cleared, PMC slot 1 contains a PCI
mezzanine card.VMEP? VMEbus present. If set, there is no VMEbus interface. If
cleared, the VMEbus interface is supported.
LANP? Ethernet present. If set, no Ethernet transceiver interface is
installed. If cleared, there is on-board Ethernet support.
SCSIP? SCSI present. If set, there is no on-board SCSI interface. If
cleared, on-board SCSI is supported.
