HUCD420038R0001工控設備，ABB使用說明
P2適配器準備MVME761轉換模塊使用三行或五行P2適配器將串行、并行和以太網信號傳輸?shù)組VME2700系列VME模塊。三排適配器在MVME761-001三排P2適配器上，一個50針公接頭（J2）還攜帶來自MVME2700板的8位SCSI信號。MVME761三排P2適配器的準備包括在以下情況下，在收割臺J1上安裝跳線以啟用SCSI端接電阻器：必需的圖1-30顯示了跳線頭的位置和MVME761的三排P2適配器上的連接器。
HUCD420038R0001工控設備有關五排P2適配器的基本準備，請參閱下一節五排適配器在MVME761-011上，MVME761的五行適配器為68針母連接器（J1）承載來自MVME2700的16位SCSI信號基板。MVME761五行P2適配器的準備包括在以下情況下，在標頭J5上安裝跳線以啟用SCSI端接電阻器：必需的圖1-19顯示了跳線頭的位置連接器和SCSI終端電源保險絲（多路開關）R4。有關準備過渡模塊和P2適配器，請參閱中列出的MVME761用戶手冊附錄D，相關文件。硬件安裝以下各節討論了夾層卡在MVME2700基板，安裝完整的MVME2700VME模塊組裝和轉換模塊到VME機箱中，以及與安裝相關的系統注意事項。在安裝之前MVME2700，確保串行端口和所有標頭跳線根據需要配置。在大多數情況下，夾層卡是RAM200 ECC DRAM模塊，可選PCI夾層（如適用）和可選載體板對于額外的PCI擴展（如果適用）-已在MVME2700。用戶可配置跳線可通過安裝夾層。如果有必要在基板上安裝夾層，請參閱以下各節簡要介紹了安裝過程。使用ESD腕帶摩托羅拉強烈建議您使用防靜電腕帶和安裝或升級系統時使用導電泡沫墊。電子的組件，如磁盤驅動器、計算機板和內存模塊，對靜電放電（ESD）極為敏感。之后從其保護包裝或系統中移除組件，將部件平放在接地的無靜電表面上（在這種情況下對于電路板，元件面朝上）。不要將部件滑過任何表面如果ESD站不可用，您可以避免因以下原因造成的損壞：佩戴防靜電腕帶進行靜電放電（電子商店有售）連接到有源接地的。請注意，系統機箱如果拔掉插頭，則可能不接地。
P2 Adapter Preparation
The MVME761 transition module uses a three-row or five-row P2 adapter
to transfer serial, parallel, and Ethernet signals to and from the
MVME2700 series VME module.
Three-Row Adapter
On the MVME761-001, three-row P2 adapter, a 50-pin male connector
(J2) also carries 8-bit SCSI signals from the MVME2700 board.
Preparation of a three-row P2 adapter for the MVME761 consists of
installing a jumper on header J1 to enable the SCSI terminating resistors if
necessary. Figure 1-30 illustrates the location of the jumper header and
connectors on the MVME761’s three-row P2 adapter.
For basic preparation of the five-row P2 adapter, refer to the next sectionFive-Row Adapter
On the MVME761-011, five-row adapter for the MVME761, a 68-pin
female connector (J1) carries 16-bit SCSI signals from the MVME2700
base board.
Preparation of a five-row P2 adapter for the MVME761 consists of
installing a jumper on header J5 to enable the SCSI terminating resistors if
necessary. Figure 1-19 illustrates the location of the jumper header, the
connectors, and SCSI terminator power fuse (polyswitch) R4.
For further information on the preparation of the transition module and the
P2 adapter, refer to the user’s manual for the MVME761, listed in
Appendix D, Related Documentation.
Hardware Installation
The following sections discuss the placement of mezzanine cards on the
MVME2700 base board, the installation of the complete MVME2700
VME module assembly and transition module into a VME chassis, and the
system considerations relevant to the installation. Before installing the
MVME2700, ensure that the serial ports and all header jumpers are
configured as desired.
In most cases, the mezzanine cards—the RAM200 ECC DRAM module,
the optional PCI mezzanine (if applicable), and the optional carrier board
for additional PCI expansion (if applicable)—are already in place on the
MVME2700. The user-configurable jumpers are accessible with the
mezzanines installed.
Should it be necessary to install mezzanines on the base board, refer to the
following sections for a brief description of the installation procedure.
Use ESD
Wrist Strap
Motorola strongly recommends that you use an antistatic wrist strap and a
conductive foam pad when installing or upgrading a system. Electronic
components, such as disk drives, computer boards, and memory modules,
can be extremely sensitive to electrostatic discharge (ESD). After
removing the component from its protective wrapper or from the system,
place the component flat on a grounded, static-free surface (and, in the case
of a board, component side up). Do not slide the component over any
surface.
If an ESD station is not available, you can avoid damage resulting from
ESD by wearing an antistatic wrist strap (available at electronics stores)
that is attached to an active electrical ground. Note that a system chassis
may not be grounded if it is unplugged.
