中止開關（S1）中止開關位于LED夾層上。當由激活時軟件中，中止開關可以從基座生成中斷信號板到處理器。中斷通常用于中止程序執行并將控制返回到位于MVME2603/2604 EPROM和閃存。中斷信號通過ISA總線中斷線IRQ8到達處理器模塊?. 信號也可在Z8536 CIO設備的引腳PB7處使用，該設備處理各種狀態信號、串行輸入/輸出線和計數器。
LT8978b,V1工控備件連接到中止開關的斷路器是一個邊緣敏感電路，過濾以消除開關反彈。
復位開關（S2）復位開關位于LED夾層上。復位開關重置所有車載設備；它還驅動系統重置? 如果MVME2603/2604是系統控制器。前面板指示燈（DS1–DS6）MVME2603/2604前面板上有六個LED：CHS、BFL、CPU、，PCI、FUS和SYS。
? CHS（DS1，黃色）。檢查停止；由MPC603/604狀態驅動MVME2603/2604上的線路。當停止條件從檢測到處理器。
? BFL（DS2，黃色）。電路板故障；BRD故障時亮起? 信號線路處于活動狀態。
? CPU（DS3，綠色）。CPU活動；DBB時亮起? （數據總線忙）處理器總線上的信號線處于活動狀態。
? PCI（DS4，綠色）。PCI活動；當IRDY? （發起人就緒）PCI總線上的信號線處于活動狀態。這表明PCI夾層或承載板（如果已安裝）處于活動狀態。
? FUS（DS5，綠色）。保險絲正常；+5V DC、+12V DC和–從基板到過渡電路提供12V直流電源模塊和遠程設備。注意，因?yàn)镕US LED監控多個電壓的狀態在MVME2603/2604中，它不直接指示狀況任何單個保險絲。如果LED閃爍或熄滅，請檢查所有保險絲（多開關）。
? SYS（DS6，綠色）。系統控制器；當宇宙發光時MVME2603/2604中的ASIC是VMEbus系統控制器。
ABORT Switch (S1)
The ABORT switch is located on the LED mezzanine. When activated by
software, the ABORT switch can generate an interrupt signal from the base
board to the processor. The interrupt is normally used to abort program
execution and return control to the debugger firmware located in the
MVME2603/2604 EPROM and Flash memory. The interrupt signal
reaches the processor module via ISA bus interrupt line IRQ8?. The signal
is also available at pin PB7 of the Z8536 CIO device, which handles
various status signals, serial I/O lines, and counters.
The interrupter connected to the ABORT switch is an edge-sensitive circuit,
filtered to remove switch bounce.
RESET Switch (S2)
The RESET switch is located on the LED mezzanine. The RESET switch
resets all onboard devices; it also drives a SYSRESET? signal if the
MVME2603/2604 is the system controller.Front Panel Indicators (DS1 – DS6)
There are six LEDs on the MVME2603/2604 front panel: CHS, BFL, CPU,
PCI, FUS, and SYS.
? CHS (DS1, yellow). Checkstop; driven by the MPC603/604 status
lines on the MVME2603/2604. Lights when a halt condition from
the processor is detected.
? BFL (DS2, yellow). Board Failure; lights when the BRDFAIL? signal
line is active.
? CPU (DS3, green). CPU activity; lights when the DBB? (Data Bus
Busy) signal line on the processor bus is active.
? PCI (DS4, green). PCI activity; lights when the IRDY? (Initiator
Ready) signal line on the PCI bus is active. This indicates that the
PCI mezzanine or carrier board (if installed) is active.
? FUS (DS5, green). Fuse OK; lights when +5V DC, +12V DC, and
–12V DC power is available from the base board to the transition
module and remote devices.
Note Because the FUS LED monitors the status of several voltages on
the MVME2603/2604, it does not directly indicate the condition
of any single fuse. If the LED flickers or goes out, check all the
fuses (polyswitches).
? SYS (DS6, green). System Controller; lights when the Universe
ASIC in the MVME2603/2604 is the VMEbus system controller.
