3HNA024871-00102機器人模塊,ABB如何使用
網絡輸入/輸出支持網絡引導固件提供了引導CPU通過ROM調試器使用網絡（本地以太網接口）作為引導設備。引導過程分兩個不同的階段執行。? 第一階段允許無盤遠程節點發現其
網絡標識和要引導的文件的名稱。? 第二階段是無盤遠程節點讀取通過網絡將文件引導到其內存中。各種模塊和這些模塊的依賴關系支持整體網絡引導功能，詳見以下段落。
3HNA024871-00102機器人模塊Intel 82596 LAN協處理器以太網驅動程序此驅動程序管理/包圍Intel 82596 LAN協處理器。
管理屬于數據包接收的范圍數據包傳輸、接收緩沖區刷新和接口初始化。
該模塊確保了以太網數據包在引導PROM中正確完成。
UDP/IP協議模塊互聯網協議（IP）設計用于互聯網絡分組交換計算機通信網絡系統。
互聯網協議提供了數據塊的傳輸從源到目標，其中源和目標是主機由固定長度地址標識。
UDP/IP協議是TFTP和BOOTP所必需的協議；TFTP和BOOTP需要UDP/IP連接。RARP/ARP協議模塊反向地址解析協議（RARP）基本上包括無身份節點將“whoami”數據包廣播到以太網，并等待答案。RARP服務器填充以太網回復數據包，包括目標的互聯網地址和發送它。
地址解析協議（ARP）基本上提供了將協議地址（例如IP地址）轉換為局域網地址（例如以太網地址）。RARP協議模塊支持不支持BOOTP協議。
Network I/O Support
The Network Boot Firmware provides the capability to boot the
CPU through the ROM debugger using a network (local Ethernet
interface) as the boot device.
The booting process is executed in two distinct phases.
? The first phase allows the diskless remote node to discover its
network identify and the name of the file to be booted.
? The second phase has the diskless remote node reading the
boot file across the network into its memory.
The various modules and the dependencies of these modules that
support the overall network boot function are described in the
following paragraphs.
Intel 82596 LAN Coprocessor Ethernet Driver
This driver manages/surrounds the Intel 82596 LAN Coprocessor.
Management is in the scope of the reception of packets, the
transmission of packets, receive buffer flushing, and interface
initialization.
This module ensures that the packaging and unpackaging of
Ethernet packets is done correctly in the Boot PROM.
UDP/IP Protocol Modules
The Internet Protocol (IP) is designed for use in interconnected
systems of packet-switched computer communication networks.
The Internet Protocol provides for transmitting of blocks of data
called datagrams (hence User Datagram Protocol, or UDP) from
sources to destinations, where sources and destinations are hosts
identified by fixed length addresses.
The UDP/IP protocols are necessary for the TFTP and BOOTP
protocols; TFTP and BOOTP require a UDP/IP connection. RARP/ARP Protocol Modules
The Reverse Address Resolution Protocol (RARP) basically consists
of an identity-less node broadcasting a "whoami" packet onto the
Ethernet, and waiting for an answer. The RARP server fills an
Ethernet reply packet up with the target's Internet Address and
sends it.
The Address Resolution Protocol (ARP) basically provides a
method of converting protocol addresses (e.g., IP addresses) to
local area network addresses (e.g., Ethernet addresses). The RARP
protocol module supports systems which do not support the
BOOTP protocol.
