Equipment Connections
Some connection diagrams are in the Single Board Computer
Programmer's Reference Guide.
The MVME712X transition modules and P2 adapter boards connect
peripheral equipment to the MVME187 as shown in Table 3-10.Console terminals, host computer
systems, modems, or serial printers
EIA-232-D serial ports on the
transition module
Parallel printers Centronics printer port on the
transition module
Optional internal modems (see the
user’s manual for your transition
module for details)
Optional modem port, replacing serial
port 2 on the transition module
Internal SCSI drives Adapter board and transition module
External SCSI drives SCSI interface connector on the
transition module
Ethernet connections Ethernet port on the transition moduleSet jumpers on the transition
module(s) and install SCSI
terminators (if needed) on the P2
adapter board.
Module Preparation in the user’s
manual for your transition module
and adapter board, and
SCSI Bus Termination on page 3-29
2 Connect and install the MVME712X
transition module in the front or the
rear of the chassis.
Installation Instructions in the user’s
manual for your transition module
and adapter board
3 Connect and install
? The P2 adapter board at the
P2 connector on the
backplane at the MVME187
slot.
Installation Instructions in the user’s
manual for your transition module
and adapter board
? SCSI cable(s) from the P2
adapter board to the
MVME712X transition
module and internal SCSI
devices.
Module Preparation in the user’s
manual for your transition module
and adapter board, and SCSI Bus
Termination on page 3-29Connecting Peripherals
The MVME187 mates with (optional) terminals or other peripherals
at the EIA-232-D serial ports (marked SERIAL PORTS 1, 2, 3, and 4
on the MVME712X transition module), parallel port, SCSI ports,
and LAN Ethernet port, as shown in Figure 3-3 on page 3-22.
Note Some cable(s) are not provided with the MVME712X
module(s), and therefore are made or provided by the
user. (Motorola recommends using shielded cables for
all connections to peripherals to minimize radiation.)
