要配置主機的網絡設置，請雙擊參數編輯器設置選項卡。將打開“主屬性”對話框。注意：您也可以通過選擇導航器的“項目”選項卡打開此對話框展開硬件配置文件夾和包含單元右鍵單擊包含IC693PBM200模塊的插槽，然后選擇網絡設置。分配給PROFIBUS主機的名稱。您可以編輯名稱或使用默認名稱名稱該名稱顯示在對話框的標題欄中（在上圖中，默認為名稱為PFB_DP_9030_MASTER）。PROFIBUS DP網絡上PROFIBUS主模塊的地址。
IDP10-AF1C01F壓力變送器大師默認情況下，模塊配置為站點0。在多主機配置中，您可以在配置的同一類型的主站和從站之間共享站號在另一個主設備中。描述PROFIBUS主設備的可選用戶定義描述。檢查器顯示最多254個字符。但是，可以在中輸入超過254個字符對話框。主設備類型PROFIBUS主設備的類型。這是一個只讀字段。設備ID PROFIBUS主設備的ID。這是一個只讀字段。資源-已使用PROFIBUS主設備使用的字節數。這是一個只讀字段。資源-可供PROFIBUS主設備使用的字節數。最大值
資源大小為16384字節?？捎觅Y源的數量取決于PROFIBUS配置的從屬設備和每個網絡參數都會自動設置。此選項卡提供了的其他配置高級用戶。波特率PROFIBUS網絡的波特率。選項有9.6 KBps、19.2 KBps、93.75 KBps和187.5 KBpsKBps、500 KBps、750 KBps、1.5 MBps、3 MBps、6 MBps、12 MBps。默認值為1.5 MBps。網絡上任何活動站點的最高可能站點地址。這會影響到花費時間尋求新的PROFIBUS主設備。默認值為126。旋轉時間網絡的最大目標令牌旋轉時間，以t_位（和毫秒）表示。網絡選項卡的時間子選項卡插槽PROFIBUS主機等待消息回復的時間量（微秒）?？臻e1 PROFIBUS主機在收到回復或Idle 2:PROFIBUS主機在發送消息之后和發送之前等待的時間量（微秒）另一條消息。就緒在發送ACK響應之前，在發送ACK響應之后，PROFIBUS主機等待的t_位數靜默PROFIBUS主機在開啟變送器后、開始發送數據之前等待的t_位數。ve的模塊、參數和診斷信息。這是一個只讀字段。
To configure network settings for the master, double-click the Network Settings field in the
Parameter Editor Settings tab. The Master Properties dialog box opens.
Note: You can also open this dialog box by selecting the Project tab of the Navigator
and expanding the Hardware configuration folder and the rack that contains the
module. Right click the slot containing the IC693PBM200 module, and choose
Network Settings.The name assigned to the PROFIBUS Master. You can edit the name or use the default
name. The name appears in the title bar of the dialog box (in the figure above, the default
name is PFB_DP_9030_MASTER).
Station The address of the PROFIBUS Master module on a PROFIBUS DP network. The master
module is configured as Station 0 by default. In a multiple master configuration, you can
share station numbers between the master and slaves of the same type that are configured
in another master device.
Description A optional user-defined description for the PROFIBUS Master device. The Inspector displays
a maximum of 254 characters. However, more than 254 characters can be entered in the
dialog box.
Master Type The type of PROFIBUS Master device. This is a read-only field.
Device ID The ID of the PROFIBUS Master device. This is a read-only field.
Resources - Used The number of bytes used by the PROFIBUS Master device. This is a read-only field.
Resources - Available The number of bytes available for use by the PROFIBUS Master device. The maximum
