ABB T3N225斷路器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
ABB T3N225 斷路器 是一款來自 ABB T3 系列的中型斷路器，專為低壓電力系統中的過載和短路保護設計。它廣泛應用于工業、商業和建筑電力分配系統中，確保電氣設備和線路在出現故障時得到有效的保護。
主要特性和技術參數
額定電流 (In)：
- ABB T3N225 斷路器的額定電流為 225 A，適用于中等負載的電氣保護。
過載保護和短路保護：
- 過載保護：可以根據實際負載情況設定，防止電流過大導致線路和設備過熱、損壞。
- 短路保護：該斷路器配備短路保護功能，能夠在出現短路情況時迅速斷開電路，防止更嚴重的故障發生。
斷路能力：
- T3N225 具有高斷路能力，能夠應對較高的短路電流，確保在極端情況下能夠迅速切斷電流，防止電氣設備損壞或火災。
電氣性能：
- 瞬時釋放 (Instantaneous trip)：當發生短路故障時，瞬時釋放特性可確保斷路器在極短的時間內斷開電路，保護系統免受損壞。
- 時間延遲釋放 (Time-delayed trip)：對于較小的過載，T3N225 斷路器支持時間延遲釋放特性，這有助于防止因短時過載（如啟動電流）而不必要的跳閘。
外形和尺寸：
- T3N225 斷路器采用緊湊的設計，適用于標準化的電氣控制柜和配電盤，確保安裝和布線的靈活性和便利性。
- 標準化的尺寸和安裝孔距，使得該斷路器可以快速替換或安裝在現有系統中。
應用范圍：
- 商業建筑：用于大型商業建筑的配電系統，保護電氣設備免受過載和短路故障影響。
- 工業設備：在制造工廠、工業生產線等場所，作為主要電力分配和保護設備，確保重要電氣設施的安全運行。
- 住宅配電：適用于大型住宅小區或多層建筑的電力分配系統中，用于確保電氣設備和負載的安全。
- 電力分配和控制系統：T3N225 在電力分配系統中擔任著關鍵角色，確保系統中每條電路的過載保護和短路防護。
耐久性與維護：
- T3N225 斷路器具有較長的使用壽命和良好的耐用性，適合于頻繁開關操作的環境。
- 該斷路器支持簡單的維護和檢查，可以在不中斷電力供應的情況下快速替換或維修。
環境適應性：
- 該斷路器設計具有較強的環境適應性，能夠在工業環境、建筑工地等較為嚴苛的工作條件下運行。
- 可以適應廣泛的工作溫度范圍，通常為 -5°C 到 40°C。
英文資料：
The ABB T3N225 circuit breaker is a medium-sized circuit breaker from the ABB T3 series, designed specifically for overload and short-circuit protection in low-voltage power systems. It is widely used in industrial, commercial, and building power distribution systems to ensure effective protection of electrical equipment and lines in the event of faults.
Main features and technical parameters
Rated current (In):
The rated current of ABB T3N225 circuit breaker is 225 A, suitable for electrical protection under medium loads.
Overload protection and short circuit protection:
Overload protection: It can be set according to the actual load situation to prevent excessive current from causing overheating and damage to the circuit and equipment.
Short circuit protection: This circuit breaker is equipped with a short circuit protection function, which can quickly disconnect the circuit in case of a short circuit, preventing more serious faults from occurring.
Circuit breaking capability:
T3N225 has high breaking capacity and can handle high short-circuit currents, ensuring that the current can be quickly cut off in extreme situations to prevent electrical equipment damage or fire.
Electrical performance:
Instantaneous trip: When a short circuit fault occurs, the instantaneous trip feature ensures that the circuit breaker disconnects the circuit in a very short time, protecting the system from damage.
Time delayed trip: For smaller overloads, the T3N225 circuit breaker supports a time delayed trip feature, which helps prevent unnecessary trips due to short-term overloads (such as starting currents).
Appearance and dimensions:
The T3N225 circuit breaker adopts a compact design, suitable for standardized electrical control cabinets and distribution panels, ensuring flexibility and convenience in installation and wiring.
The standardized size and installation hole spacing enable the circuit breaker to be quickly replaced or installed in existing systems.
Application scope:
Commercial buildings: used for power distribution systems in large commercial buildings to protect electrical equipment from overload and short circuit faults.
Industrial equipment: As the main power distribution and protection equipment in manufacturing factories, industrial production lines, and other places, it ensures the safe operation of important electrical facilities.
Residential power distribution: suitable for power distribution systems in large residential communities or multi story buildings, used to ensure the safety of electrical equipment and loads.
Power distribution and control system: T3N225 plays a critical role in the power distribution system, ensuring overload protection and short-circuit protection for each circuit in the system.
Durability and maintenance:
T3N225 circuit breaker has a long service life and good durability, suitable for environments with frequent switching operations.
This circuit breaker supports simple maintenance and inspection, and can be quickly replaced or repaired without interrupting power supply.
Environmental adaptability:
The circuit breaker design has strong environmental adaptability and can operate under harsh working conditions such as industrial environments and construction sites.
It can adapt to a wide range of working temperatures, typically from -5 ° C to 40 ° C.
