PM864AK01 3BSE018161R1處理器單元模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
ABB PM864AK01 (3BSE018161R1) 處理器單元模塊是ABB AC 800M 控制器系列的一部分，設計用于高性能和高可靠性的工業自動化應用。它是一個功能強大的 CPU 模塊，支持廣泛的控制任務和復雜的過程自動化需求。以下是關于該模塊的詳細信息：
主要功能和特點
高性能處理能力
- 配備強大的 CPU，支持快速處理復雜的邏輯控制任務。
- 高速任務周期，適用于實時過程控制和數據處理。
模塊化設計
- 可靈活與 I/O 模塊、通信模塊和冗余模塊組合，適應多種應用場景。
- 支持熱插拔功能，便于在線維護和擴展。
冗余支持
- 支持 CPU 冗余配置，實現高可用性，適用于關鍵控制任務。
- 冗余切換快速且無縫，確保系統連續運行。
多通信接口
- 內置以太網接口，用于與控制網絡和上位機通信。
- 支持多種協議，包括 Modbus TCP/IP、PROFINET、EtherNet/IP 等，適應不同的工業網絡需求。
強大的環境適應性
- 工業級設計，能夠在惡劣環境下運行。
- 具有抗電磁干擾、防振動的能力，適用于各種工業環境。
編程和配置
- 兼容 ABB 的 Control Builder 編程工具，支持 IEC 61131-3 標準的多種編程語言。
- 支持在線調試和診斷功能，便于故障排查和優化。
技術規格
| 參數 | 詳情 |
|---|---|
| 型號 | PM864AK01 (3BSE018161R1) |
| 處理器 | 高性能工業處理器 |
| 內存容量 | 程序存儲器：4 MB；數據存儲器：1 MB |
| 通信接口 | 2 × 以太網（RJ45），支持 TCP/IP |
| 冗余支持 | CPU 和電源冗余 |
| 工作電源 | 24V DC |
| 工作溫度范圍 | -25°C 至 +70°C |
| 尺寸 | 標準模塊尺寸，便于控制柜集成 |
| 安裝方式 | DIN 導軌或機架式安裝 |
| 兼容性 | 適用于 AC 800M 系列系統 |
應用領域
過程自動化
- 石油化工、制藥、食品和飲料行業的復雜過程控制。
能源和電力
- 發電廠和輸配電系統的自動化和保護控制。
制造業
- 自動化生產線和設備的集中控制。
基礎設施
- 水處理、供暖和制冷系統的集中管理。
運輸
- 港口、機場等物流和運輸系統的控制。
英文資料：
The ABB PM864AK01 (3BSE018161R1) processor unit module is part of the ABB AC 800M controller series, designed for high-performance and high reliability industrial automation applications. It is a powerful CPU module that supports a wide range of control tasks and complex process automation requirements. The following is detailed information about the module:
Main functions and features
High performance processing capability
Equipped with a powerful CPU, it supports fast processing of complex logical control tasks.
High speed task cycle, suitable for real-time process control and data processing.
Modular design
It can be flexibly combined with I/O modules, communication modules, and redundant modules to adapt to various application scenarios.
Support hot swappable function for easy online maintenance and expansion.
Redundant support
Support CPU redundancy configuration, achieve high availability, suitable for critical control tasks.
Redundant switching is fast and seamless, ensuring continuous system operation.
Multiple communication interfaces
Built in Ethernet interface for communication with control network and upper computer.
Supports multiple protocols, including Modbus TCP/IP, PROFINET, EtherNet/IP, etc., to meet different industrial network requirements.
Strong environmental adaptability
Industrial grade design, capable of operating in harsh environments.
It has the ability to resist electromagnetic interference and vibration, and is suitable for various industrial environments.
Programming and Configuration
Compatible with ABB's Control Builder programming tool, supporting multiple programming languages according to IEC 61131-3 standard.
Support online debugging and diagnostic functions for easy troubleshooting and optimization.
technical specifications
Parameter details
Model PM864AK01 (3BSE018161R1)
High performance industrial processor
Memory capacity: Program storage: 4 MB; Data storage: 1 MB
Communication interface 2 x Ethernet (RJ45), supporting TCP/IP
Redundancy supports CPU and power redundancy
Working power supply 24V DC
Working temperature range -25 ° C to+70 ° C
Standard module size for easy control cabinet integration
Installation method: DIN rail or rack mounted installation
Compatibility for AC 800M series systems
application area
process automation
Complex process control in the petrochemical, pharmaceutical, food, and beverage industries.
Energy and Electricity
Automation and protection control of power plants and transmission and distribution systems.
manufacturing
Centralized control of automated production lines and equipment.
infrastructure
Centralized management of water treatment, heating, and cooling systems.
transport
Control of logistics and transportation systems such as ports and airports.
