WATLOW ANAFAZE CLS204溫度控制器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Watlow Anafaze CLS204 溫度控制器是一個多通道溫度控制設備，專為工業和實驗室應用設計，能夠精確監測和調節多路溫度信號。該控制器以其可靠性、靈活性和高性能著稱，適用于多區域溫度控制需求。以下是關于 CLS204 溫度控制器的詳細信息：
主要功能和特點
多通道溫度控制
- 支持多達 4 個獨立控制回路，適合復雜的多區域溫度管理需求。
- 每個通道均可獨立編程，以滿足不同的溫度要求。
高精度控制
- 提供 PID 控制算法，支持自動調節功能，實現高精度溫度控制。
- 響應速度快，溫度波動小。
靈活的輸入類型
- 支持多種傳感器輸入，包括 熱電偶（T/C）和 RTD。
- 兼容多種傳感器類型，便于集成現有系統。
用戶友好接口
- 配備數字顯示屏，可實時顯示當前溫度和設定值。
- 簡單易用的菜單導航，便于快速設置和調整。
通信能力
- 支持 RS-232 或 RS-485 通信協議，可與 PLC 或上位機系統集成。
- 提供遠程監控和數據記錄功能。
報警和安全功能
- 支持高溫、低溫報警，確保系統安全運行。
- 可配置繼電器輸出，用于報警或緊急停機。
技術規格
| 參數 | 詳情 |
|---|---|
| 控制回路數量 | 4 路獨立回路 |
| 控制方式 | PID、自整定控制 |
| 輸入類型 | 熱電偶（J、K、T、E）和 RTD（Pt100） |
| 輸出類型 | SSR 驅動、繼電器、線性電壓/電流輸出 |
| 通信接口 | RS-232 或 RS-485 |
| 電源要求 | 85-264 VAC，50/60 Hz |
| 工作溫度范圍 | 0°C 至 +50°C |
| 安裝方式 | 面板安裝 |
| 尺寸 | 1/4 DIN 或其他標準尺寸 |
應用領域
工業過程控制
- 多區域加熱設備控制，如塑料成型、熱處理和涂裝工藝。
實驗室和研發
- 多點溫度監控和調節，適用于精密測試設備。
食品和飲料
- 用于烘焙、發酵和溫度敏感工藝的控制。
半導體制造
- 精確控制溫度對生產良率有關鍵影響的制造工藝。
英文資料：
The Watlow Anafaze CLS204 temperature controller is a multi-channel temperature control device designed specifically for industrial and laboratory applications, capable of accurately monitoring and adjusting multiple temperature signals. This controller is known for its reliability, flexibility, and high performance, and is suitable for multi zone temperature control requirements. The following is detailed information about the CLS204 temperature controller:
Main functions and features
Multi channel temperature control
Supports up to 4 independent control loops, suitable for complex multi zone temperature management needs.
Each channel can be independently programmed to meet different temperature requirements.
High precision control
Provide PID control algorithm, support automatic adjustment function, and achieve high-precision temperature control.
Fast response speed and minimal temperature fluctuations.
Flexible input types
Supports multiple sensor inputs, including thermocouples (T/C) and RTDs.
Compatible with multiple sensor types, making it easy to integrate with existing systems.
User friendly interface
Equipped with a digital display screen, it can display the current temperature and set value in real time.
Simple and easy-to-use menu navigation for quick setup and adjustment.
Communication capability
Supports RS-232 or RS-485 communication protocols and can be integrated with PLC or upper computer systems.
Provide remote monitoring and data recording functions.
Alarm and safety functions
Support high and low temperature alarms to ensure the safe operation of the system.
Configurable relay output for alarm or emergency shutdown.
technical specifications
Parameter details
Control circuit quantity: 4 independent circuits
Control method PID, self-tuning control
Input type thermocouple (J, K, T, E) and RTD (Pt100)
Output type SSR driver, relay, linear voltage/current output
Communication interface RS-232 or RS-485
Power requirement 85-264 VAC, 50/60 Hz
Working temperature range: 0 ° C to+50 ° C
Installation method: Panel installation
Size 1/4 DIN or other standard sizes
application area
industrial process control
Multi zone heating equipment control, such as plastic molding, heat treatment, and coating processes.
Laboratory and R&D
Multi point temperature monitoring and adjustment, suitable for precision testing equipment.
Food and Beverage
Used for controlling baking, fermentation, and temperature sensitive processes.
Semiconductor Manufacturing
Precise temperature control is a manufacturing process that has a critical impact on production yield.
2.產 品 展 示
