YOKOGAWA AAI141-H50 S2 模擬輸入模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
YOKOGAWA AAI141-H50 S2 是一款 模擬輸入模塊，用于Yokogawa的控制系統（如CENTUM系列和ProSafe-RS等）中。該模塊的主要功能是從各種傳感器和現場設備接收模擬信號，將其轉換為數字信號，并傳輸給控制系統進行處理。
主要特點：
- 模塊類型: 模擬輸入模塊
- 輸入信號: 支持多種模擬輸入信號類型，如電壓信號和電流信號（通常是4-20mA）。
- 通道數量: 該型號通常提供多個輸入通道，可同時接收多路信號（一般為16通道或類似配置）。
- 精確度: 提供高精度的信號轉換，確保輸入信號的準確采集。
- 隔離設計: 模塊內部通常具備通道與通道、通道與系統之間的電氣隔離，避免電氣噪聲或故障的影響，增強系統可靠性。
- 熱插拔支持: 模塊可以在系統運行時進行更換，無需關閉系統，減少維護停機時間。
- 冗余支持: 支持冗余配置，提升系統的可靠性和故障恢復能力。
應用場景：
- 過程控制: 廣泛應用于過程自動化行業，如石油化工、能源、制造業中，接收傳感器和現場設備的模擬信號，進行實時監控和控制。
- 工業自動化: 作為自動化系統中的重要組成部分，適用于需要高精度信號采集的場合，如壓力、溫度、流量等物理量的測量。
- 能源管理: 用于監控和管理電力、能源系統中的關鍵參數，確保穩定運行和高效管理。
特點總結：
- 高精度輸入: 確保從傳感器和現場設備獲取的模擬信號能夠精確轉換為數字信號，進行進一步處理和控制。
- 電氣隔離: 提高系統的安全性和可靠性，避免電氣干擾對數據采集的影響。
- 多通道輸入: 支持多路信號同時輸入，適合大規模過程控制和自動化系統。
- 熱插拔功能: 提供便捷的維護和升級支持，減少系統停機時間。
- 冗余支持: 為關鍵應用場合提供更高的可靠性和系統可用性。
英文資料：
YOKOGAWA AAI141-H50 S2 is an analog input module used in Yokogawa's control systems, such as the CENTUM series and ProSafe RS. The main function of this module is to receive analog signals from various sensors and field devices, convert them into digital signals, and transmit them to the control system for processing.
Main features:
Module type: Analog input module
Input signal: Supports multiple types of analog input signals, such as voltage signals and current signals (usually 4-20mA).
Channel quantity: This model usually provides multiple input channels and can simultaneously receive multiple signals (usually 16 channels or similar configurations).
Accuracy: Provides high-precision signal conversion to ensure accurate acquisition of input signals.
Isolation design: Modules typically have electrical isolation between channels and between channels and systems to avoid the impact of electrical noise or faults and enhance system reliability.
Hot swappable support: Modules can be replaced during system operation without shutting down the system, reducing maintenance downtime.
Redundancy support: Supports redundant configuration to enhance system reliability and fault recovery capabilities.
Application scenarios:
Process control: widely used in the process automation industry, such as petrochemicals, energy, and manufacturing, to receive analog signals from sensors and on-site equipment for real-time monitoring and control.
Industrial automation: As an important component of automation systems, it is suitable for situations that require high-precision signal acquisition, such as the measurement of physical quantities such as pressure, temperature, and flow rate.
Energy management: used to monitor and manage key parameters in power and energy systems, ensuring stable operation and efficient management.
Summary of Characteristics:
High precision input: Ensure that analog signals obtained from sensors and field devices can be accurately converted into digital signals for further processing and control.
Electrical isolation: Improve the safety and reliability of the system, and avoid the impact of electrical interference on data acquisition.
Multi channel input: supports simultaneous input of multiple signals, suitable for large-scale process control and automation systems.
Hot swappable function: Provides convenient maintenance and upgrade support, reducing system downtime.
Redundancy support: providing higher reliability and system availability for critical application scenarios.
2.產 品 展 示
