ASE2UDC920AE01模塊卡件,ASE2UDC920AE01如何使用
絕緣放大器PXUB 201絕緣放大器連接到張力電子設備電壓輸出。S1通常設置為1:1的電壓比。選擇輸出以通過開關S1和S2產生電壓或電流輸出。通過開關S2位置3選擇較慢的響應。開關位于裝置內部。使用外部開/關開關（未提供）啟動和關閉張力電子設備ABB）。在正常操作期間，無需操作員采取任何行動。1、檢查主張力控制機械是否準備好正常運行。
ASE2UDC920AE01模塊卡件2.通過將外部開/關開關設置為on位置，打開張力電子設備。對于IP 65版本（NEMA 4），也將內部開關設置為“ON”。3、檢查：-顯示屏亮了-“電源”指示燈亮起-“狀態”指示燈亮起（綠燈）。紅燈表示錯誤。通過將外部開/關開關設置為關閉位置，關閉張力電子設備。4.5正常運行測量設備應永久開啟，以獲得最佳測量結果。這使得稱重傳感器和電子設備能夠在穩定的溫度條件下工作。測量設備設計用于連續操作。顯示的測量值示例：示例1：選定單位[N]，稱重傳感器標稱負載100 kN，測量值987654 N。顯示值：987600 N。示例2：選定單位[kN]，稱重傳感器標稱負載100 kN，測量值987654 N。顯示值：987.6 kN。與設置小數功能一起顯示的測量值示例：示例1：選定單元[pli]，稱重傳感器標稱負載1 kN，測量值46.5987 pli。設置小數=2顯示值：46.60 pli。示例2：選定單元[pli]，稱重傳感器標稱負載1 kN，測量值46.5987 pli。設置小數=0顯示值：47 pli。 Insulation Amplifier PXUB 201
The insulation amplifier is connected to the tension electronics voltage output.
S1 is normally set for voltage 1:1 ratio.
The output is selected to generate a voltage or current output by means of switch S1 and S2.
Slower response is selected by means of switch S2, position 3.
The switches are located inside the unitThe tension electronics is started and shut down using an external ON/OFF switch (not supplied
by ABB). During normal operation no action from the operator is required.
1. Check that the main tension control machinery is ready for normal run.
2. Switch on the tension electronics by setting the external ON/OFF switch to position ON.
For the IP 65-version (NEMA 4) also set the internal switch to “ON”.
3. Check that:
- the display is illuminated
- the “Power” indicator is lit
- the “Status” indicator is lit (green light). Red light indicates an error.
Shut-down the tension electronics by setting the external ON/OFF switch to position OFF.
4.5 Normal Run
The measurement equipment should be on permanently to achieve the best measurement results.
This allows the load cells and electronics to operate under stable temperature conditions.
The measuring equipment is designed for continuous operation. Examples of measuring values displayed:
Example 1:
Selected unit [N], Load cell nominal load 100 kN, Measured value 987654 N.
Value presented on display: 987600 N.
Example 2:
Selected unit [kN], Load cell nominal load 100 kN, Measured value 987654 N.
Value presented on display: 987.6 kN.
Examples of measuring values displayed together with the Set Decimals function:
