IS200TVBAH2ACC燃機電氣模塊,IS200TVBAH2ACC使用區(qū)域
如果機柜要相互安裝，請使用隨附的螺釘/螺栓套件。四個M8螺釘，帶墊圈和螺母，在角鉸鏈和六個M6螺釘中，Z1=500，Z2=1000，Z3=距地面1500 mm的高度，見圖2-8。將M8螺釘擰緊至最大扭矩為20 Nm將機柜固定到地板上時，最大扭矩為10 Nm的M6螺釘使用四個或六個M12螺釘，其中圖2-9所示為一個在一排機柜中的第一個左側機柜的每個角落，擰緊以下機柜右側各有兩個螺釘。
IS200TVBAH2ACC燃機電氣模塊底角鉸鏈具有孔，直徑14毫米（0.6英寸）。這些孔允許您在安裝孔后調整機柜位置在地板上鉆孔。如果需要鉆孔，確保沒有灰塵或其他異物進入機柜中的設備。請注意機柜到墻壁的最小距離，以及天花板在地板和機柜底部之間使用墊圈，將機柜地板調平至水平位置?？臻g要求機柜的外形尺寸如中的尺寸圖所示附錄A.7圖紙。以下規(guī)則適用于機柜的定位：?機柜頂面與梁的屋頂、拱腹或通風管等必須至少為250 mm。如果電纜從上方進入，則該距離為增加到1000毫米。?機柜后部和墻壁之間必須有至少40 mm的間隙，在櫥柜兩側和墻壁之間。?允許帶鉸鏈的框架或外部封裝的門完全打開，而無需在相鄰墻壁上，與墻壁的距離必須增加到500 mm門框鉸鏈側（左側），或車門鉸鏈側（右側）300 mm。機柜前必須有至少1米的可用空間。必須能夠完全打開門，以免限制退房和維修。If cabinets are to be mounted to each other use the included screw/bolt kit. The four M8 screws,
with washers and nuts, in the angle hinges and six M6 screws at about Z1=500, Z2=1000,
Z3=1500 mm height from the floor, see Figure 2-8. Tighten the M8 screws to 20 Nm maximum
and the M6 screws to 10 Nm maximumWhen fixing the cabinet to the floor use four or six M12 screws where Figure 2-9 indicates, one
at each corner in the first left hand cabinet in a row of cabinets and screw the following cabinets
with two screws each at the right hand side. The bottom angle hinges features holes,
14 mm (0.6”) in diameter. These holes permit you to adjust the cabinet location after holes are
drilled in the floor. If drilling is necessary, make sure that no dust or other foreign matter enters
the equipment in the cabinet. Please notice the minimum distances from cabinet to walls and
ceiling. Use washers between the floor and the cabinet bottom to level the cabinet floor into a
horizontal position.Space Requirements
The overall dimensions of the cabinet are shown in a dimension diagram in
Appendix A.7 Drawings.
The following rules apply to locating and positioning of the cabinet:
? The distance between the top surface of the cabinet and the roof, soffit of a beam or
ventilation duct etc. must be at least 250 mm. If cables enter from above, this distance is
increased to 1000 mm.
? There must be a clearance of at least 40 mm between the rear of the cabinet and the wall,
and between the sides of the cabinet and the wall.
? To permit a frame with hinge, or a door to an outer encapsulation to open fully without
catching on the adjacent wall, the distance to the wall must be increased to 500 mm on the
hinge side (left) of the frame, or 300 mm on the hinge side (right) of the door.
? There must be at least 1 meter of free space in front of the cabinet. It must be possible to
open the door completely, in order not to restrict access for check-out and servicing.
