The Modbus commands which read and write to data tables require a reference (starting point) and, in
some cases, the number of points. The Modbus command reference provided and the PLC data table
element accessed by the RTU module in the PLC are not necessarily equal as described below.
Originally, the Modbus protocol was only meant to access 4 different data tables with limited writing of
data. The RTU module expands these limitations by performing reference mapping. The RTU module
contains a map of PLC data tables and assigns a range of associated Modbus references to each data
table.Therefore, the user can access more than one PLC data table with a single Modbus command by simply
changing the reference. The tables above describe the sub-divided regions of the Modbus reference to
access the appropriate data table.Each model of the PLC CPU contains a different maximum number of points for each data table. During
initialization of the RTU module, the CPU is interrogated for the size of each of its data tables. Should a
Modbus reference andDial the Number Immediately Following this Command
Where n = digits 0 to 9, the symbols # and *, and may include the dial modifiers listed below.
The modem will dial the number specified in the manner determined by the dial modifiers. The dial
modifiers may appear anywhere within the dial string with the exception of the ; modifier which must
appear at the end of the string.In this example the modem pulse dials a 9-digit number, waits for a dial tone, then tone dials the digits
713. It then dials the number 123-4567. Finally, the modem returns to the command mode after the final
digit has been dialed.
The P modifier causes the modem to pulse or rotary dial at a fixed rate of 10 pulses per second.
The T modifier causes the modem to dial using DTMF (Dual-tone multifrequency) signals (the same as
those used by “touch-tone” telephones)The "," modifier causes the modem to pause. When dialing a long distance service, for example, the
modem must first dial the local access number, then pause long enough for the services dial tone. The ","
is also useful when dialing from a PBX system where considerable time may elapse between requesting
and getting a secondary dial tone or "outside" line.
The @ modifier causes the modem to wait for 3 seconds for one or more rings followed by 5 seconds of
silence before processing the next symbol in the dial string. This is useful when accessing systems that
do not provide a dial tone.
