369B1859G0022 電流互感器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
369B1859G0022 是一種電流互感器，通常用于電力系統中的電流測量和保護。電流互感器（CT）是一種將高電流轉換為較小、可管理的電流信號的設備，方便測量、保護和控制系統的集成。
主要特點和功能
電流轉換：
- 369B1859G0022 將高電流（如主電流）轉換為較低的標準電流值，通常是 1A 或 5A。這個低電流值可以安全地輸入到測量儀器、保護設備或控制系統中。
測量和監控：
- 用于電力系統中以監控電流的流量，確保系統運行在安全范圍內?？梢耘c電流表、保護繼電器和其他測量設備配合使用。
保護功能：
- 在電力系統發生故障（如過電流）時，電流互感器能提供準確的電流信號，幫助保護設備進行斷電或報警處理，防止設備損壞或電力系統故障擴大。
絕緣和安全：
- 設計有良好的絕緣性能，以確保高電壓環境下的安全操作。防止高電流對測量設備或人員造成危險。
高精度：
- 提供高精度的電流測量，確保數據準確性和系統的可靠運行。
技術規格（示例）
- 額定電流：通常會有額定 primary 電流值，如 100A、200A、500A 等，以及轉換后的 secondary 電流值，如 1A、5A。
- 額定比率：轉換比率，例如 1000:5，表示 primary 電流為 1000A 時，secondary 電流為 5A。
- 精度等級：通常為 0.1、0.2、0.5 級，表示測量精度。
- 絕緣等級：電流互感器的絕緣等級，如 Class A 或 Class B，以適應不同的工作環境。
- 頻率響應：能夠測量的頻率范圍，通常與電力系統的頻率（50Hz 或 60Hz）一致。
- 外形和安裝：包括尺寸、安裝方式（如環形、穿心式），適應不同的安裝需求。
英文資料：
369B1859G0022 is a current transformer commonly used for current measurement and protection in power systems. A current transformer (CT) is a device that converts high currents into smaller, manageable current signals, facilitating the integration of measurement, protection, and control systems.
Main features and functions
Current conversion:
369B1859G0022 converts high currents (such as main currents) into lower standard current values, typically 1A or 5A. This low current value can be safely input into measuring instruments, protective equipment, or control systems.
Measurement and monitoring:
Used in power systems to monitor the flow of current and ensure that the system operates within a safe range. Can be used in conjunction with ammeters, protective relays, and other measuring devices.
Protection function:
When a fault occurs in the power system (such as overcurrent), current transformers can provide accurate current signals to help protect equipment from power outages or alarm processing, preventing equipment damage or the expansion of power system faults.
Insulation and safety:
The design has good insulation performance to ensure safe operation in high voltage environments. Prevent high current from causing danger to measuring equipment or personnel.
high-precision:
Provide high-precision current measurement to ensure data accuracy and reliable system operation.
Technical specifications (example)
Rated current: There are usually rated primary current values, such as 100A, 200A, 500A, etc., as well as converted secondary current values, such as 1A, 5A.
Rated ratio: Conversion ratio, for example 1000:5, indicates that when the primary current is 1000A, the secondary current is 5A.
Accuracy level: usually 0.1, 0.2, 0.5, indicating measurement accuracy.
Insulation level: The insulation level of current transformers, such as Class A or Class B, to adapt to different working environments.
Frequency response: The frequency range that can be measured, usually consistent with the frequency of the power system (50Hz or 60Hz).
Appearance and installation: including dimensions, installation methods (such as circular and through type), to meet different installation requirements.
