362A1052P004 火焰檢測器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
362A1052P004 是一款火焰檢測器，通常用于工業燃燒過程中的火焰監測。這種類型的設備廣泛應用于燃燒系統中，如鍋爐、燃?xì)獍l(fā)電機、加熱器等，以確保燃燒過程的安全性和效率。
主要特點和功能
高靈敏度探測：
- 設計為能夠檢測到微弱的火焰信號，確保能夠在燃燒過程中準確監測火焰狀態。
多種探測技術：
- UV探測器：適用于高溫火焰的監測，常用于燃燒器和鍋爐中。
- IR探測器：適合檢測不同波長的紅外輻射，常用于多種燃燒過程中的火焰監測。
- 362A1052P004 火焰檢測器可能采用紫外（UV）或紅外（IR）探測技術，具體取決于型號和應用需求：
實時監測與報警：
- 提供實時火焰監測和報警功能，在火焰異常時發出警報，以防止設備損壞或潛在的安全隱患。
高可靠性與耐用性：
- 設計用于工業環境，具有耐高溫、抗干擾的能力，確保長期穩定運行。
兼容性與集成：
- 可以與多種控制系統兼容，通常提供標準的輸出信號（如開關量、4-20mA），便于與現有的控制系統集成。
故障診斷：
- 部分型號配備自診斷功能，能夠自動檢測并報告設備狀態，幫助維護人員及時發現和解決問題。
技術規格（示例）
- 探測方式：紫外（UV）或紅外（IR）探測（具體取決于型號）。
- 電源要求：例如24V DC、110V AC或220V AC，具體電源要求根據型號而定。
- 輸出信號：通常包括開關量輸出（繼電器輸出）、模擬信號（如4-20mA）等。
- 工作溫度范圍：一般設計為在-20°C到+70°C范圍內可靠工作。
- 響應時間：快速響應，確保及時檢測和報警。
應用領域
燃燒系統：
- 用于燃燒器、鍋爐、加熱器等設備中的火焰監測，確保燃燒過程的穩定性和安全性。
燃?xì)獍l(fā)電機：
- 在燃?xì)獍l(fā)電機中應用，監測火焰狀態，防止設備損壞或停機。
石化和化工行業：
- 在石化和化工過程中監測火焰狀態，確保生產過程的安全。
電力行業：
- 在電力行業的燃燒設備中使用，確保設備的安全運行和高效工作。
安裝與維護
安裝：
- 應將火焰檢測器安裝在能夠有效監測火焰的位置，確保探測器的視線范圍內沒有障礙物，避免直接受到振動、灰塵或高溫的影響。
維護：
- 定期檢查和清潔探測窗口，以防止灰塵或污垢影響探測性能。
- 進行定期功能測試，確保設備在實際運行中的有效性和可靠性。
英文資料：
362A1052P004 is a flame detector commonly used for flame monitoring in industrial combustion processes. This type of equipment is widely used in combustion systems, such as boilers, gas generators, heaters, etc., to ensure the safety and efficiency of the combustion process.
Main features and functions
High sensitivity detection:
Designed to detect weak flame signals and ensure accurate monitoring of flame status during combustion.
Multiple detection techniques:
The 362A1052P004 flame detector may use ultraviolet (UV) or infrared (IR) detection technology, depending on the model and application requirements:
UV detector: suitable for monitoring high-temperature flames, commonly used in burners and boilers.
IR detector: suitable for detecting infrared radiation of different wavelengths, commonly used for flame monitoring in various combustion processes.
Real time monitoring and alarm:
Provide real-time flame monitoring and alarm functions, issuing alerts in case of abnormal flames to prevent equipment damage or potential safety hazards.
High reliability and durability:
Designed for industrial environments, it has the ability to withstand high temperatures and interference, ensuring long-term stable operation.
Compatibility and Integration:
It can be compatible with multiple control systems and usually provides standard output signals (such as switch values, 4-20mA), making it easy to integrate with existing control systems.
Fault diagnosis:
Some models are equipped with self diagnostic function, which can automatically detect and report equipment status, helping maintenance personnel to discover and solve problems in a timely manner.
Technical specifications (example)
Detection method: UV or IR detection (depending on the model).
Power requirements: For example, 24V DC, 110V AC, or 220V AC, the specific power requirements depend on the model.
Output signal: usually includes switch output (relay output), analog signal (such as 4-20mA), etc.
Operating temperature range: Generally designed to operate reliably within the range of -20 ° C to+70 ° C.
Response time: Fast response, ensuring timely detection and alarm.
application area
Combustion system:
Used for flame monitoring in equipment such as burners, boilers, heaters, etc., to ensure the stability and safety of the combustion process.
Gas generator:
Applied in gas generators, monitor flame status to prevent equipment damage or shutdown.
Petrochemical and chemical industry:
Monitor flame status in petrochemical and chemical processes to ensure production safety.
Power industry:
Used in combustion equipment in the power industry to ensure safe operation and efficient operation of the equipment.
Installation and maintenance
Installation:
The flame detector should be installed in a position that can effectively monitor the flame, ensuring that there are no obstacles within the detector's line of sight and avoiding direct impact from vibration, dust, or high temperature.
maintain:
Regularly inspect and clean the detection window to prevent dust or dirt from affecting detection performance.
Conduct regular functional testing to ensure the effectiveness and reliability of the equipment during actual operation.
2.產 品 展 示
