Bently 3500/93 135785-02C 系統顯示器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Bently Nevada 3500/93 135785-02C 系統顯示器是 3500 系列機械保護和狀態監測系統中的一部分，專用于工業環境下的振動監測和診斷應用。該模塊作為系統顯示器，主要用于提供系統狀態的可視化顯示，幫助用戶監控和診斷設備運行狀況。
主要特點
實時數據顯示: 3500/93 系統顯示器能夠?qū)崟r顯示來自 3500 系列監測模塊的數據，包括振動、軸位移、轉速等關鍵參數。這有助于操作人員在現場實時監控設備的運行狀態。
多種顯示模式: 該顯示器支持多種數據顯示模式，如趨勢圖、條形圖、數值顯示等，用戶可以根據需要選擇最合適的顯示方式。
用戶界面: 提供友好的用戶界面，支持多語言顯示，操作簡便，易于理解和使用。用戶可以通過前面板的按鈕和菜單系統來導航和配置顯示內容。
數據存儲與檢索: 該顯示器具有一定的歷史數據存儲能力，可以存儲一段時間內的關鍵參數變化，方便后續的故障分析和趨勢預測。
模塊化設計: 3500/93 系統顯示器作為 3500 系列的一部分，可以與其他 3500 系列模塊無縫集成，確保整個系統的兼容性和擴展性。
應用領域
旋轉機械保護: 廣泛應用于石油、天然氣、電力、化工等行業的旋轉機械（如渦輪機、壓縮機、泵等）監測，幫助防止機械故障，減少意外停機時間。
振動監測: 通過實時顯示振動數據，幫助維護人員快速識別設備的異常狀態，從而采取預防性維護措施，延長設備的使用壽命。
工廠自動化: 在工廠自動化系統中，作為監測系統的一部分，實時監控關鍵設備的運行狀態，確保生產過程的安全性和可靠性。
技術規格
顯示屏類型: 通常為 LCD 或 LED 顯示屏，支持高亮度和寬視角顯示。
分辨率: 高分辨率顯示，能夠清晰顯示復雜的圖表和數據。
通信接口: 支持與 3500 系列其他模塊的通信，通常通過內部總線或?qū)Ｓ媒涌趯崿F(xiàn)數據傳輸。
電源需求: 通常為 24VDC 或通過背板供電，功耗較低。
尺寸與安裝: 模塊化設計，符合 3500 系列標準機架尺寸，易于安裝和維護。
英文資料：
The Bently Nevada 3500/93 135785-02C system monitor is part of the 3500 series mechanical protection and condition monitoring system, specifically designed for vibration monitoring and diagnostic applications in industrial environments. This module serves as a system display, mainly used to provide visual display of system status, helping users monitor and diagnose equipment operation status.
main features
Real time data display: The 3500/93 system monitor can display real-time data from the 3500 series monitoring modules, including key parameters such as vibration, shaft displacement, and speed. This helps operators to monitor the real-time operation status of the equipment on site.
Multiple display modes: This monitor supports multiple data display modes, such as trend charts, bar charts, numerical displays, etc. Users can choose the most suitable display mode according to their needs.
User Interface: Provides a user-friendly interface, supports multilingual display, is easy to operate, and is easy to understand and use. Users can navigate and configure display content through the buttons and menu system on the front panel.
Data storage and retrieval: This display has a certain historical data storage capability, which can store key parameter changes over a period of time, facilitating subsequent fault analysis and trend prediction.
Modular design: As part of the 3500 series, the 3500/93 system monitor can seamlessly integrate with other 3500 series modules, ensuring compatibility and scalability of the entire system.
application area
Rotating machinery protection: widely used for monitoring rotating machinery (such as turbines, compressors, pumps, etc.) in industries such as petroleum, natural gas, power, and chemical, helping to prevent mechanical failures and reduce unexpected downtime.
Vibration monitoring: By displaying real-time vibration data, maintenance personnel can quickly identify abnormal states of equipment, take preventive maintenance measures, and extend the service life of equipment.
Factory automation: In the factory automation system, as part of the monitoring system, real-time monitoring of the operating status of key equipment is carried out to ensure the safety and reliability of the production process.
technical specifications
Display screen type: usually LCD or LED display screen, supporting high brightness and wide viewing angle display.
Resolution: High resolution display, capable of clearly displaying complex charts and data.
Communication interface: Supports communication with other modules in the 3500 series, usually through internal buses or dedicated interfaces for data transmission.
Power requirement: Usually 24VDC or powered through the backplane, with low power consumption.
Size and Installation: Modular design, compliant with 3500 series standard rack dimensions, easy to install and maintain.
2.產 品 展 示
