GE SR745-W2-P1-G1-HI-A-L-R-E保護繼電器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE SR745-W2-P1-G1-HI-A-L-R-E 保護繼電器是GE Multilin生產的高級變壓器保護和管理繼電器，專門用于提供變壓器的綜合保護、控制和監視。它在電力行業中有廣泛的應用，尤其是用于發電廠、變電站和工業設施中。以下是關于這款繼電器的詳細信息：
主要功能和特性
差動保護:
- 該繼電器提供高靈敏度的差動保護功能，能夠檢測變壓器繞組之間的差動電流，識別內部故障，如匝間短路、繞組接地故障等。
過流保護:
- 提供多種過流保護功能，包括瞬時過流、定時過流和反時限過流保護，確保在短路和其他異常電流情況下，迅速切斷故障電路，保護變壓器免受損壞。
過載保護:
- 監控變壓器的負載情況，防止長時間的過載運行，避免因過熱導致的絕緣損壞和設備壽命縮短。
溫度監控:
- 內置溫度監控功能，能夠?qū)崟r監測變壓器的繞組和油溫，提供報警和跳閘功能，以防止變壓器過熱。
勵磁涌流阻斷:
- 通過識別勵磁涌流特征，防止誤跳閘，確保變壓器在投入運行時的穩定性。
通信功能:
- 支持多種通信協議（如Modbus、DNP3、IEC 61850等），能夠與其他保護設備、控制系統進行數據交換，支持遠程監控和控制。
事件記錄和波形捕捉:
- 具有事件記錄和波形捕捉功能，可以記錄和分析電力系統的故障事件，為故障排查和系統優化提供數據支持。
自動化和控制:
- 支持自動化操作，例如自動重合閘、負載切換和故障隔離，提升系統的運行效率和可靠性。
英文資料：
The GE SR745-W2-P1-G1-HI-A-L-R-E protection relay is an advanced transformer protection and management relay produced by GE Multilin, specifically designed to provide comprehensive protection, control, and monitoring of transformers. It has a wide range of applications in the power industry, especially in power plants, substations, and industrial facilities. The following is detailed information about this relay:
Main functions and features
Differential protection:
This relay provides high sensitivity differential protection function, which can detect differential current between transformer windings, identify internal faults such as turn to turn short circuits, winding grounding faults, etc.
Overcurrent protection:
Provide multiple overcurrent protection functions, including instantaneous overcurrent, timed overcurrent, and inverse time overcurrent protection, to ensure that the fault circuit is quickly cut off in case of short circuit and other abnormal current situations, protecting the transformer from damage.
Overload protection:
Monitor the load condition of the transformer to prevent long-term overload operation, avoid insulation damage caused by overheating, and shorten equipment life.
Temperature monitoring:
Built in temperature monitoring function, capable of real-time monitoring of transformer windings and oil temperature, providing alarm and trip functions to prevent transformer overheating.
Excitation surge blocking:
By identifying the characteristics of excitation inrush current, it prevents false tripping and ensures the stability of the transformer during operation.
Communication function:
Supports multiple communication protocols (such as Modbus, DNP3, IEC 61850, etc.), can exchange data with other protection devices and control systems, and supports remote monitoring and control.
Event recording and waveform capture:
Equipped with event recording and waveform capture functions, it can record and analyze fault events in the power system, providing data support for fault diagnosis and system optimization.
Automation and Control:
Support automated operations such as automatic reclosing, load switching, and fault isolation to improve system efficiency and reliability.
