SR745-W2-P1-G1-HI-A-L-R 變壓器管理繼電器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
SR745-W2-P1-G1-HI-A-L-R 是一款由GE Multilin生產的變壓器管理繼電器。這個繼電器廣泛應用于變壓器的保護和控制系統中，特別是在電力和工業領域。以下是該產品的主要應用領域和功能：
1. 變壓器保護
- 過載保護：能夠檢測并響應變壓器的過載情況，避免因長時間超負荷運行導致的設備損壞。
- 過流保護：提供短路和故障情況下的快速響應，以防止進一步的設備損壞。
- 差動保護：用于檢測變壓器繞組之間或繞組與接地之間的差動電流，以識別內部故障。
- 溫度保護：監控變壓器的溫度，防止過熱情況的發生，從而延長變壓器的使用壽命。
2. 電力系統管理
- 自動化控制：該繼電器支持自動化操作，例如自動重合閘和負荷切換，優化電力系統的效率和穩定性。
- 監控與記錄：SR745能夠記錄電力系統中的各種事件和故障，提供詳細的診斷數據，幫助操作人員進行故障排查和系統優化。
- 通信功能：具備多種通信協議，可以與其他電力系統設備進行數據交換，支持遠程監控和控制。
3. 電力行業
- 發電廠：在發電廠中，SR745繼電器用于保護和管理大型變壓器，確保電力生成和傳輸?shù)姆€(wěn)定性。
- 變電站：作為變電站自動化系統的一部分，用于保護和控制變壓器設備，防止因設備故障導致的電力中斷。
- 輸配電網絡：在輸配電網絡中，該繼電器有助于監控和管理變壓器的運行狀態，優化電力的傳輸和分配。
英文資料：
SR745-W2-P1-G1-HI-A-L-R is a transformer management relay produced by GE Multilin. This relay is widely used in the protection and control systems of transformers, especially in the fields of power and industry. The following are the main application areas and functions of this product:
1. Transformer protection
Overload protection: capable of detecting and responding to transformer overload situations, avoiding equipment damage caused by long-term overload operation.
Overcurrent protection: Provides rapid response in the event of short circuits and faults to prevent further equipment damage.
Differential protection: used to detect differential current between transformer windings or between windings and ground, in order to identify internal faults.
Temperature protection: Monitor the temperature of the transformer to prevent overheating and extend its service life.
2. Power system management
Automated control: This relay supports automated operations such as automatic reclosing and load switching, optimizing the efficiency and stability of the power system.
Monitoring and Recording: SR745 can record various events and faults in the power system, provide detailed diagnostic data, and assist operators in troubleshooting and system optimization.
Communication function: It has multiple communication protocols, can exchange data with other power system equipment, and supports remote monitoring and control.
3. Power industry
Power plants: In power plants, SR745 relays are used to protect and manage large transformers, ensuring the stability of power generation and transmission.
Substation: As a part of the substation automation system, it is used to protect and control transformer equipment to prevent power outages caused by equipment failures.
Transmission and distribution network: In the transmission and distribution network, this relay helps to monitor and manage the operating status of transformers, optimize the transmission and distribution of electricity.
2.產 品 展 示
