Problem reports generated by function code 150 are I/O error
reports (report type 12). Function code 150 problem reports
generate one error type: Error type 1 - No response/wrong type
(refer to Tables 6-3 and 6-4).
TROUBLESHOOTING HARDWARE FAILURES
Effectively troubleshoot a hardware failure by using the flowcharts to isolate the failure (see Figures 6-3 and 6-3). After
locating the failure, refer to the text or other reference documents for more information about the failure and the corrective action. Contact the manufacturer for control loop processhardware troubleshooting information. The first part of this
section covers off-line failures. If the failure is preventing calibration, tuning or module start-up, refer to OFF-LINE FAILURE and the steps of the troubleshooting procedure. The
second part covers failures during operation. If the failure
occurs during operation, refer to ON-LINE FAILURE and the
steps of the troubleshooting procedure.
NOTE: Troubleshooting involves physical contact with the system,
including the handling of boards with electrostatic sensitive devices.
To avoid creating additional problems while troubleshooting, always
use Bailey’s field static kit (part number 1948385_1) when working
with the modules. The kit is designed to connect a technician and
the static dissipative work surface to the same ground point to prevent damage to the modules by electrostatic discharge.
