Multilin 369-HI-R-B-F-0電機管理繼電器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Multilin 369-HI-R-B-F-0 電機管理繼電器是 GE Multilin 系列中的一款高級保護設備，專為電動機的保護、監控和管理設計。它提供全面的保護功能，確保電動機的安全運行，防止因故障導致的設備損壞或停機。
主要應用領域
電動機保護
- 提供過流、堵轉、短路、過熱、欠壓等保護功能。
- 適用于各種電動機的保護，包括風機、泵、壓縮機等工業設備。
工業自動化
- 在工業自動化系統中，用于監測和控制電動機，確保設備的正常運行。
- 提供實時狀態監測和故障診斷，優化生產線運行。
發電廠和變電站
- 在發電廠和變電站中，作為電動機控制系統的一部分，提供電動機保護和控制功能。
- 處理發電機驅動的電動機的保護任務，確保發電和變電設備的安全性。
主要特點
全面的保護功能
- 過流保護：檢測和保護電動機免受過流情況的影響。
- 堵轉保護：防止電動機在堵轉時發生損壞。
- 過熱保護：監測電動機溫度，防止過熱導致的損壞。
- 欠壓保護：保護電動機免受欠壓情況的影響。
- 短路保護：檢測短路故障并采取相應的保護措施。
智能化功能
- 故障診斷：提供詳細的故障診斷功能，幫助用戶識別和解決問題。
- 事件記錄：記錄故障事件和操作歷史，支持故障分析和報告生成。
- 趨勢分析：分析電動機的運行趨勢，預測潛在問題。
高精度測量
- 提供高精度的電流、電壓、溫度等測量數據。
- 支持實時監測，確保電動機的安全和穩定運行。
靈活的配置
- 提供多種保護設置和配置選項，滿足不同應用需求。
- 支持參數調整和自定義設置，以適應不同電動機的保護要求。
用戶友好的界面
- 直觀的操作界面和顯示屏，方便用戶進行設置和操作。
- 提供圖形化的數據顯示，提升用戶體驗。
通信能力
- 支持多種通信協議，如Modbus、DNP3、IEC 61850等。
- 提供以太網、RS485、RS232等多種通信接口，方便與其他系統集成。
英文資料：
The Multilin 369-HI-R-B-F-0 motor management relay is an advanced protection device in the GE Multilin series, designed specifically for the protection, monitoring, and management of electric motors. It provides comprehensive protection functions to ensure the safe operation of the motor and prevent equipment damage or shutdown caused by faults.
Main application areas
Motor protection
Provide protection functions such as overcurrent, locked rotor, short circuit, overheating, undervoltage, etc.
Suitable for the protection of various electric motors, including industrial equipment such as fans, pumps, compressors, etc.
industrial automation
In industrial automation systems, it is used to monitor and control electric motors to ensure the normal operation of equipment.
Provide real-time status monitoring and fault diagnosis to optimize production line operation.
Power plants and substations
In power plants and substations, as part of the motor control system, provide motor protection and control functions.
Handle the protection tasks of electric motors driven by generators to ensure the safety of power generation and transformation equipment.
main features
Comprehensive protection function
Overcurrent protection: detects and protects the motor from the impact of overcurrent conditions.
Locking protection: prevents damage to the motor during locking.
Overheating protection: Monitor the temperature of the motor to prevent damage caused by overheating.
Undervoltage protection: protects the motor from the effects of undervoltage conditions.
Short circuit protection: detect short circuit faults and take corresponding protective measures.
Intelligent functions
Fault diagnosis: Provide detailed fault diagnosis functions to help users identify and solve problems.
Event recording: Record fault events and operation history, support fault analysis and report generation.
Trend analysis: Analyze the operating trend of the electric motor and predict potential problems.
High precision measurement
Provide high-precision measurement data for current, voltage, temperature, etc.
Support real-time monitoring to ensure the safe and stable operation of the electric motor.
Flexible configuration
Provide multiple protection settings and configuration options to meet different application needs.
Support parameter adjustment and custom settings to meet the protection requirements of different motors.
User friendly interface
Intuitive operation interface and display screen, convenient for users to set up and operate.
Provide graphical data display to enhance user experience.
Communication capability
Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850, etc.
Provide multiple communication interfaces such as Ethernet, RS485, RS232, etc. for easy integration with other systems.
2.產 品 展 示
