Multilin F650BFCF1G1HI6保護繼電器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Multilin F650BFCF1G1HI6 保護繼電器是 GE Multilin 系列中的一種高性能保護設備，專為電力系統中的關鍵設備提供保護功能。它主要用于保護變壓器、發電機、電動機等設備免受電氣故障的影響，確保電力系統的安全和穩定運行。
主要應用領域
變壓器保護
- 保護變壓器免受過流、短路、過載、過溫等故障的影響。
- 監測變壓器的運行狀態，提供及時的報警和斷電功能，防止設備損壞。
發電機保護
- 對發電機進行過流、短路、失磁、欠壓等保護，確保發電機的正常運行。
- 提供發電機運行狀態的實時監測和故障診斷功能。
電動機保護
- 保護電動機免受過流、堵轉、過溫、缺相等故障的影響。
- 提供電動機的運行狀態監測和故障報警功能，確保電動機的可靠運行。
配電系統保護
- 用于配電系統中，提供過流、短路、接地故障等保護。
- 確保配電系統的穩定性和可靠性，防止電氣故障擴散。
主要特點
全面的保護功能
- 提供多種保護功能，如過流、短路、欠壓、過溫、接地故障等。
- 具備靈活的保護設置和自定義功能，滿足不同應用需求。
高精度測量
- 采用高精度的測量技術，實時監測電力系統的參數。
- 提供準確的故障檢測和診斷，確保設備的安全運行。
智能化功能
- 具備智能化的故障分析和報警功能，提供詳細的故障記錄和報告。
- 支持事件記錄和趨勢分析，幫助用戶了解系統運行狀態和故障原因。
用戶友好的界面
- 提供直觀的顯示界面和圖形化操作界面，方便用戶進行設置和操作。
- 支持觸摸屏操作和圖形化顯示，提高用戶體驗。
通信能力
- 支持多種通信協議，如Modbus、DNP3、IEC 61850等，方便與其他系統集成。
- 提供以太網、RS485、RS232等多種通信接口，支持遠程監控和數據傳輸。
配置和維護
- 支持遠程配置和維護，方便用戶進行系統管理和故障排查。
- 提供詳細的文檔和技術支持，幫助用戶進行設備配置和維護。
英文資料：
The Multilin F650BFCF1G1HI6 protection relay is a high-performance protection device in the GE Multilin series, designed to provide protection for critical equipment in power systems. It is mainly used to protect equipment such as transformers, generators, and motors from electrical faults, ensuring the safe and stable operation of the power system.
Main application areas
Transformer protection
Protect transformers from the effects of faults such as overcurrent, short circuit, overload, and overheating.
Monitor the operating status of transformers, provide timely alarm and power-off functions, and prevent equipment damage.
Generator protection
Protect the generator from overcurrent, short circuit, demagnetization, undervoltage, and other factors to ensure its normal operation.
Provide real-time monitoring and fault diagnosis functions for the operation status of the generator.
Motor protection
Protect the motor from the effects of overcurrent, locked rotor, overheating, phase loss and other faults.
Provide monitoring and fault alarm functions for the operation status of electric motors to ensure their reliable operation.
Power distribution system protection
Used in power distribution systems to provide protection against overcurrent, short circuit, and grounding faults.
Ensure the stability and reliability of the power distribution system to prevent the spread of electrical faults.
main features
Comprehensive protection function
Provide multiple protection functions, such as overcurrent, short circuit, undervoltage, overtemperature, grounding fault, etc.
It has flexible protection settings and customization functions to meet different application needs.
High precision measurement
Adopting high-precision measurement technology to monitor the parameters of the power system in real-time.
Provide accurate fault detection and diagnosis to ensure the safe operation of equipment.
Intelligent functions
Equipped with intelligent fault analysis and alarm functions, providing detailed fault records and reports.
Support event recording and trend analysis to help users understand the system's operating status and fault causes.
User friendly interface
Provide an intuitive display interface and graphical user interface for convenient settings and operations.
Support touch screen operation and graphical display to improve user experience.
Communication capability
Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850, etc., for easy integration with other systems.
Provide multiple communication interfaces such as Ethernet, RS485, RS232, etc., supporting remote monitoring and data transmission.
Configuration and maintenance
Support remote configuration and maintenance, facilitating system management and troubleshooting for users.
Provide detailed documentation and technical support to assist users in device configuration and maintenance.
2.產 品 展 示
