MULTILIN MIFPI11E100H00數字饋電繼電器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
MULTILIN MIFPI11E100H00數字饋電繼電器是一種用于電力系統保護和控制的設備，設計用于配電網絡中的饋線保護。該繼電器具有先進的保護功能、靈活的通信能力和高可靠性，廣泛應用于各種配電系統中。
主要應用領域
配電網絡保護
- 適用于電力公司的配電網絡，提供線路保護和故障隔離。
- 用于中低壓配電線路的保護，確保供電的連續性和安全性。
工業電力系統
- 在工業企業的電力系統中應用，保護關鍵負載和設備。
- 適用于制造業、石油化工、鋼鐵、礦業等行業的電力保護。
智能電網
- 在智能電網系統中，用于智能化的配電保護和監控。
- 提供數據采集和遠程監控功能，支持電網的智能化管理。
分布式能源系統
- 適用于風電、光伏等分布式能源系統，提供保護和控制功能。
- 確保分布式能源系統的穩定運行和安全并網。
主要特點
全面的保護功能
- 過流保護：包括瞬時、定時限、反時限過流保護。
- 接地故障保護：快速檢測并響應接地故障。
- 負序電流保護：檢測和保護不平衡電流故障。
- 斷路器失靈保護：檢測斷路器故障并進行后備保護。
先進的監控和測量
- 實時監測電流、電壓、功率、頻率等參數。
- 提供故障錄波和事件記錄功能，幫助故障分析和排除。
- 顯示和記錄諧波、電能質量等高級測量數據。
靈活的通信功能
- 支持多種通信協議，如Modbus、DNP3、IEC 61850等。
- 提供以太網、RS485、RS232等多種接口，支持遠程監控和數據傳輸。
- 集成SCADA系統，實現全面的配電網絡管理。
用戶友好的界面
- 配備LCD顯示屏和按鍵，方便現場操作和設置。
- 支持基于PC的軟件工具，便于遠程配置和維護。
高可靠性和環境適應性
- 設計堅固耐用，適應各種工業和戶外環境。
- 提供抗電磁干擾、防塵、防水等多種防護功能。
英文資料：
MULTILIN MIFPI111E100H00 digital feed relay is a device used for power system protection and control, designed for feeder protection in distribution networks. This relay has advanced protection functions, flexible communication capabilities, and high reliability, and is widely used in various distribution systems.
Main application areas
Distribution network protection
Suitable for the distribution network of power companies, providing line protection and fault isolation.
Used for the protection of medium and low voltage distribution lines, ensuring the continuity and safety of power supply.
Industrial power system
Applied in the power system of industrial enterprises to protect critical loads and equipment.
Suitable for power protection in industries such as manufacturing, petrochemicals, steel, and mining.
Smart grid
In smart grid systems, it is used for intelligent distribution protection and monitoring.
Provide data collection and remote monitoring functions to support intelligent management of the power grid.
Distributed Energy System
Suitable for distributed energy systems such as wind power and photovoltaics, providing protection and control functions.
Ensure the stable operation and safe grid connection of distributed energy systems.
main features
Comprehensive protection function
Overcurrent protection: including instantaneous, timed, and inverse time overcurrent protection.
Ground fault protection: Quickly detect and respond to ground faults.
Negative sequence current protection: detects and protects against unbalanced current faults.
Circuit breaker failure protection: detect circuit breaker faults and provide backup protection.
Advanced monitoring and measurement
Real time monitoring of parameters such as current, voltage, power, frequency, etc.
Provide fault recording and event recording functions to assist in fault analysis and troubleshooting.
Display and record advanced measurement data such as harmonics and power quality.
Flexible communication capabilities
Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850, etc.
Provide multiple interfaces such as Ethernet, RS485, RS232, etc., supporting remote monitoring and data transmission.
Integrate SCADA system to achieve comprehensive distribution network management.
User friendly interface
Equipped with an LCD display screen and buttons for easy on-site operation and setup.
Support PC based software tools for remote configuration and maintenance.
High reliability and environmental adaptability
Designed to be sturdy and durable, suitable for various industrial and outdoor environments.
Provide multiple protective functions such as anti electromagnetic interference, dust prevention, and waterproofing.
2.產 品 展 示
