MULTILIN 12BDD18B1A變壓器
1.產 品 資 料 介 紹：
中文資料：
MULTILIN 12BDD18B1A 是 GE Multilin 系列中的一款變壓器保護設備。它專為變壓器保護設計，能夠提供全面的保護、監控和控制功能，以確保變壓器的安全穩定運行。以下是有關 MULTILIN 12BDD18B1A 變壓器保護設備的詳細信息：
主要特性和功能
變壓器保護功能：
- 過電流保護： 檢測變壓器的電流是否超出設定值，提供過電流保護，以防止變壓器因電流過高而受損。
- 過載保護： 監控變壓器負載情況，提供過載保護，以防止長期負荷超載造成損壞。
- 差動保護： 通過比較變壓器的輸入和輸出電流，提供差動保護，檢測內部故障并防止進一步的損壞。
- 接地故障保護： 檢測變壓器的接地故障，防止因接地問題引發的安全隱患。
- 過溫保護： 監測變壓器的溫度，提供過溫保護，防止因過熱導致的設備損壞。
監控與診斷：
- 實時數據監控： 實時監控變壓器的電流、電壓、功率等參數，確保變壓器在正常范圍內運行。
- 事件記錄： 記錄保護事件、故障信息和報警記錄，幫助進行故障診斷和系統維護。
- 自診斷功能： 內置自診斷功能，定期檢查設備的運行狀態，確保系統的正常工作。
通信與集成：
- 多種通信接口： 支持 RS-232、RS-485、以太網等多種通信接口，便于與其他設備和系統的集成。
- 支持標準通信協議： 兼容 Modbus、DNP3 等工業標準通信協議，實現數據的有效傳輸和集成。
用戶界面與配置：
- 顯示屏： 配備 LCD 顯示屏，直觀顯示變壓器的運行狀態和保護參數。
- 配置與編程： 提供用戶友好的界面，便于配置和編程，調整保護設置和運行參數。
- 遠程訪問： 支持遠程訪問和管理，用戶可以通過網絡對設備進行遠程監控和配置。
高可靠性設計：
- 工業級設計： 采用工業級組件，確保設備在惡劣環境下的穩定性和可靠性。
- 冗余設計： 提供冗余電源輸入和信號路徑，確保在主系統故障時仍能正常工作。
英文資料：
MULTILIN 12BDD18B1A is a transformer protection device in the GE Multilin series. It is designed specifically for transformer protection, providing comprehensive protection, monitoring, and control functions to ensure the safe and stable operation of transformers. The following is detailed information about the MULTILIN 12BDD18B1A transformer protection equipment:
Main features and functions
Transformer protection function:
Overcurrent protection: detects whether the current of the transformer exceeds the set value, provides overcurrent protection to prevent the transformer from being damaged due to excessive current.
Overload protection: Monitor the load condition of the transformer, provide overload protection to prevent damage caused by long-term overload.
Differential protection: By comparing the input and output currents of transformers, differential protection is provided to detect internal faults and prevent further damage.
Grounding fault protection: Detecting grounding faults in transformers to prevent safety hazards caused by grounding issues.
Over temperature protection: Monitor the temperature of the transformer, provide over temperature protection, and prevent equipment damage caused by overheating.
Monitoring and Diagnosis:
Real time data monitoring: Real time monitoring of transformer parameters such as current, voltage, and power to ensure that the transformer operates within the normal range.
Event recording: Record protection events, fault information, and alarm records to assist in fault diagnosis and system maintenance.
Self diagnostic function: Built in self diagnostic function, regularly checks the operating status of the equipment to ensure the normal operation of the system.
Communication and Integration:
Multiple communication interfaces: Supports various communication interfaces such as RS-232, RS-485, Ethernet, etc., making it easy to integrate with other devices and systems.
Support standard communication protocols: compatible with industrial standard communication protocols such as Modbus and DNP3, achieving effective data transmission and integration.
User interface and configuration:
Display screen: Equipped with an LCD display screen, it intuitively displays the operating status and protection parameters of the transformer.
Configuration and Programming: Provides a user-friendly interface for easy configuration and programming, adjusting protection settings and operating parameters.
Remote Access: Supports remote access and management, allowing users to remotely monitor and configure devices through the network.
High reliability design:
Industrial grade design: using industrial grade components to ensure the stability and reliability of equipment in harsh environments.
Redundant design: Provide redundant power input and signal paths to ensure normal operation in the event of a main system failure.
application area
Power system: Suitable for transformer protection in power plants, substations, and distribution networks to ensure stable operation of the power system.
Industrial automation: used for transformer protection in industrial automation systems to enhance the level of intelligence and safety of the system.
Manufacturing: Applied in the manufacturing industry to protect critical transformer equipment and ensure stability and safety during the production process.
2.產 品 展 示
