MULTILIN GEHDACAB電機管理器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Multilin GEHDACAB 電機管理器是 GE 的 Multilin 系列中的一款高級電機保護和管理設備，專為電機提供全面的保護、監控和控制功能。以下是關于 Multilin GEHDACAB 電機管理器的詳細信息：
主要特性和功能
電機保護功能：
- 過載保護： 實時監測電機的電流，防止過載情況導致的電機損壞。
- 堵轉保護： 在電機啟動和運行時檢測堵轉情況，并提供保護以防止電機損壞。
- 斷相保護： 檢測電源缺相或不平衡情況，防止因缺相對電機造成的損壞。
- 過電壓/欠電壓保護： 保護電機免受電壓波動的影響。
- 短路保護： 檢測異常電流情況，提供短路保護以防止電機受損。
- 熱保護： 通過溫度監測防止電機過熱，保護電機的正常運行。
- 地漏電流保護： 監測并保護因絕緣故障引起的地漏電流問題。
監控與診斷：
- 實時監控： 提供實時的電流、電壓、功率和其他關鍵參數的監控。
- 故障診斷： 記錄故障事件并提供詳細的診斷信息，幫助快速定位和解決問題。
- 數據記錄： 存儲歷史數據和事件記錄，便于后續分析和審計。
通信與集成：
- 通信協議： 支持多種工業標準通信協議，如 Modbus RTU、Modbus TCP/IP、DNP3 和 IEC 61850，便于與其他控制系統集成。
- 遠程監控： 通過通信接口支持遠程訪問和監控，簡化維護和管理工作。
用戶界面：
- 顯示屏： 配備 LCD 顯示屏，用于實時顯示電機的運行狀態和參數。
- 操作界面： 友好的用戶界面，方便進行設置和調整。
- 可編程性： 提供可編程的輸入/輸出選項，以滿足特定應用需求。
擴展功能：
- 多種保護算法： 提供多種保護算法，適應不同類型電機的保護需求。
- 靈活配置： 可根據具體應用需求進行配置，確保系統的靈活性和可擴展性。
英文資料：
The Multilin GEHDACAB motor manager is an advanced motor protection and management device in GE's Multilin series, designed to provide comprehensive protection, monitoring, and control functions for motors. The following is detailed information about the Multilin GEHDACAB motor manager:
Main features and functions
Motor protection function:
Overload protection: Real time monitoring of motor current to prevent motor damage caused by overload situations.
Blocked rotor protection: Detect the situation of blocked rotor during motor start-up and operation, and provide protection to prevent motor damage.
Phase loss protection: detects power supply phase loss or imbalance to prevent damage to the motor caused by phase loss.
Overvoltage/undervoltage protection: protects the motor from voltage fluctuations.
Short circuit protection: detects abnormal current conditions and provides short circuit protection to prevent motor damage.
Thermal protection: Prevent motor overheating through temperature monitoring and ensure the normal operation of the motor.
Ground leakage current protection: Monitor and protect against ground leakage current issues caused by insulation faults.
Monitoring and Diagnosis:
Real time monitoring: Provides real-time monitoring of current, voltage, power, and other key parameters.
Fault diagnosis: Record fault events and provide detailed diagnostic information to help quickly locate and solve problems.
Data recording: Store historical data and event records for subsequent analysis and auditing.
Communication and Integration:
Communication Protocol: Supports multiple industrial standard communication protocols, such as Modbus RTU, Modbus TCP/IP, DNP3, and IEC 61850, making it easy to integrate with other control systems.
Remote monitoring: Supports remote access and monitoring through communication interfaces, simplifying maintenance and management work.
User interface:
Display screen: Equipped with an LCD display screen for real-time display of the motor's operating status and parameters.
Operating Interface: A user-friendly interface that facilitates settings and adjustments.
Programmable: Provides programmable input/output options to meet specific application requirements.
Extended functions:
Multiple protection algorithms: Provide multiple protection algorithms to meet the protection needs of different types of motors.
Flexible configuration: It can be configured according to specific application requirements to ensure the flexibility and scalability of the system.
2.產 品 展 示
